[quotemsg=19257951,0,1282978][quotemsg=19257707,0,528675]
And that is exactly the data they used as starting point. 8C Zen on pair with 8C Broadwell: ~107% vs 115%.
But we were comparing 6C Zen vs 4C Kabylake here.
The problem, which apparently everyone is ignoring, is on the clocks. Everyone, including myself was expecting the 4C Zen to have higher clocks than the 8C Zen. I expected about 13% higher clocks for the 65W 4C. But all the information and leaks claim that the 8C Zen has the higher clocks of the whole Zen family.
Even if Zen has an average throughput-per-clock (IPC+SMT) close to Broadwell, the 6C Zen has nearly 30% lower clocks than Kabylake.
Now the question is why those lower clocks for the 6C and the 4C Zen. I advanced two possible explanations: 14LPP and CCX. I will further extend.
[[ 14LPP ]]
Despite people believing the contrary, 14LPP is a Low Power node. It is not 14HP. I expected about 3.0/3.5GHz clocks for the 95W 8C Zen. It seems fully confirmed there exists a 3.4/3.8GHz PC/PR chip (F4 steeping). This is 11% higher clocks than I expected.
There is a 3.6/4.0GHz PC/PR chip (also F4 steeping) but according to CPCHardware this is not a 95W chip. CPCHardware didn't give us the exact TDP, but if data available is accurate we can try to estimate the TDP for that top SKU
95W * (3.6/3.4)^2 = 106W
95W * (3.6/3.4)^3 = 113W
Let us assume it is a 110W chip, which agrees with CPCHardware claim the TDP is "above 100W". Ok.
By silicon laws, and even common sense, the 4C Zen would have higher clocks. I expected 3.4GHz (but my baseline was my former estimation of 3.0GHz for the 95W 8C). Using the new 3.4GHz 95W 8C chip as baseline, we obtain for the 65W 4C Zen
3.4GHz * ROOT2 [ 2* (65/95) ] = 4.0GHz
3.4GHz * ROOT3 [ 2* (65/95) ] = 3.8GHz
Let us take 3.9GHz as base clock for a 65W 4C Zen on F4. However, the 4C Zen is rumored by everyone to come with much lower clocks. A possible explanation is that AMD is selecting the 8C chips (a la FX-9000 series) to get the higher possible clocks, leaving the normal silicon (the one cannot clock so high) for the rest of (cheaper) chips.
This is a possible explanation for the discrepancy between my predictions for clocks and reported clocks. It is like if I had predicted the clocks for the FX-8350 (average silicon) but AMD had started launching a FX-9590 (golden silicon). This analogy is not completely accurate, of course, because one is a 125W chip and the other is 220W, but you get the point.
If this explanation is correct, it says us why the 6C Zen has lower clocks. A 95W 6C Zen would have clocks ~4GHz. This would be the common sense approach. This is what Intel does, with its 140W 6C Broadwell achieving higher clocks than its 140W 8C Broadwell. Indeed taking the 3.2GHz base for the 8C Broadwell we obtain for a 6C Broadwell
3.2GHz * ROOT2 [ 8/6 ] = 3.7GHz
3.2GHz * ROOT3 [ 8/6 ] = 3.5GHz
And, unsurprisingly, the i7-6850K has a base clock of 3.6GHz.
However, if the 8C Zen chips are already in the upper limit of the 14LPP silicon, then a 95W 6C Zen couldn't achieve ~4GHz clocks. Only option left for AMD would be to reduce the TDP to 65W and ship it with lower clocks: 3.3GHz.
The 8C Zen must be close to the 8C Broadwell, because clocks are close, but the 6C Zen is being "destroyed" by a higher-clocked 4C Kabylake on heavily multithreaded benches. Ouch!
[[ CCX ]]
Another possible explanation for the lower clocks is the weird CCX approach. It is weird because one doesn't waste time designing a modular approach just to then ignore the modules and treat each core independently. We don't know the fine details of the CCX, but we know that performance varies depending of the topology. Not all 4C Zen are the same, the 4+0 chips perform differently than the 2+2 chips and the 3+1 chips.
Maybe this weird combination of modules plus individual core treatment is the origin for the lower clocks on lower core models. Maybe to avoid the unbalances generated by different active core topologies (4+0 is not the same than 2+2 evidently) it is needed to synchronize the pair of CCX in a module in a special way, just to make believe the OS that all 4C chips are the same. If this special synchronization exists it could add extra latency (from CCXtoCCX communication) and hurt clocks. Recall that f_max is a function of the length of the critical datapath.
This could explain why only the chips with full modules achieve the higher clocks, whereas the chips with less than 8C have clocks problems.
Time will say...
What are you even talking about here, you lost me on talking about modules when we already know a Zen is not a module design.
It is so scary how little the active world knows about Zen, AMD likes it because it has clearly caused distress among Intel and it's faithful, trying illogically cling to "40%" or "2x Excavator" like AMD would be content with that if they could achieve 3-4X the performance.
A 6C/6T Ryzen with low clocks inside 10% of a 6800K with 12 thread is quite impressive actually, it shows how innefficient Hyperthreading is and maybe that is the reason for the second part, Intel needs clockspeed to mask inability to push IPC which has been stagnant since Haswell.
I agree with your sentiment on CPC's tweet on Intel being flustered, they are legitimately concerned and I think they already know that this could be Hammer all over again, and the way they tried to hush the Radeon deal was quaint in Intel style. Intel's Iris works but at a rediculous cost that OEMs are just running off to get Mobile GPU's rather for the same price and 2-3 times the performance at entry level, their iGPU's are rediculously big, Vega is small so dump a Vega on your die to open more space fore more compute units to try push IPC up. This makes sense, but the irony is AMD would milk royalties in the billions and with AMD being a very low operation cost company now, these millions are just making them stronger, eventually the GloFo deal will look like the cheapest steal in history with GF taking a very minicule cut because they wanted a top end heavy deal upfront which AMD paid out debt upfront which may be another one of Lisa Su's masterstrokes.[/quotemsg]
Zen isn't build using modules in the way the constructions cores were- however we do know (based on info from AMD themselves) that Zen is built in 4 core blocks, in a similar way to the Jaguar 4 core cpu's used in the consoles (being 2 x 4c blocks rather than a monolithic 8 core). That does mean that there is some inter chip communication required between the two blocks. The concept of a theoretical 4 core being produced from a defective 8 core die could result in less than optimal performance is you wind up with the cores split between the two groups of 4. I must admit I was expecting AMD to release Zen with a separate 8 and 4 core die- which would remove this as a potential issue, although perhaps they aren't bothering as they will get a quad core Zen die out with the APU later in the year (and then can always produce another 'Athlon x4' without the gpu if they want to).
That said, I'm not convinced that a 4C kaby will 'destroy' a 6C zen in well threaded apps, that doesn't seem to add up, however as a gaming chip I can see it being sub optimal for *most* games.[/quotemsg]
I saw what he meant, he was talking about Zeppelin dies.
I believe by the code 61 instead of 66 it implies that AMD are actually using a pure hexcore. That more than makes sense for 10% slower performance and why a 4.5+ Ghz i7 with 8 threads may be faster.
Sadly i think R3-R5-R7 thing will stick)...... i think
