AMD CPU speculation... and expert conjecture

[8350rocks]

A crazy idea

I read somewhat that one of main limitations of BD/PD modules was the single decode per module. If I understood this well, the decode switches between cores within a module which means cannot feed both cores in one clock. For a ten clock period, the situation would look like (A denotes first core working, B denotes second core working and _ denotes a core is not being feed)

A_
_B
A_
_B
A_
_B
A_
_B
A_
_B

Now Steamroller has twice decoders, which means each core can be feed in one clock

AB
AB
AB
AB
AB
AB
AB
AB
AB
AB

Each core in Steamroller module is being twice more efficient than in bulldozer/piledriver module, earning twice more instructions. To get the same number of A and B (10 each) one would use two bulldozer/piledriver modules

A_ A_
_B _B
A_ A_
_B _B
A_ A_
_B _B
A_ A_
_B _B
A_ A_
_B _B

I know this is an oversimplification but could this partially explain why 4C/8C Piledriver are being replaced by 2C/4C Steamroller?

wow!... an actual AMD uarch probably related Steamroller post, in a AMD uarch "expert" Steamroller thread ????? ... naa! i think "juanrga" is derailing the thread lol

elas!.. NO decode is not the main problem... it can be, depends on the software(compiler)... the problem with decode its the same as "If" a single core per "decode engine", that is if it were there only 1 integer core would be the same problem, i.e., in x86 the "complex" decode pipe blocks the others upon more complex instructions to decode, that is, upon more than 1 MacroOp( 2 microOPs, execute + memory), the 4 decode pipe acts like if it were only 1... the same thing happens with intel uarchs.(edt)

*IF* (not easy due to the "strong dependency model" of x86, which "a priori" sees every instruction dependent on another)... it was possible that upon decoding "complex" instructions the "complex decode pipe" doesn't block the others, the "same 4 decode" pipes would act like more 2 decode engines(or more) than else...

I think that is what happens with "Steamroller", it has the same 4 decode pipes of BD/PD, only perhaps instructions from one thread don't block instructions from the other thread, that is, Steamroller must have 2 "complex" decode pipes on those 4, that assume "non-dependent" instructions by checking the "contexts", and relax the dependency checking.

Yes... steamroller most probably will have the same 4 decode pipes of BD/PD... only arranged in a different fashion.

The question of "Vertical Multi-Threading" is not the culprit either, actually it is what makes it clearly superior to any intel uarch, that VMT works upon 2 "open contexts", that is, its incredible fast "internally changing the thread contexts" ( otherwise if it were OS dependent it would be slower than a Pentium I (quite slow) lol).. and the operation is inherently "asynchronous" (quite difficult).

VMT work like this.. .contexts can change from 1 cycle to another

AA or BB ... of course A_ or B_ or _ _ can happen... ( but there NEVER is AB or BA, that is SMT and no context changing needed) (edt)... but can happen also in STM (simultaneous multithreading = hyperthreading)... or in single cores... caches misses always leads to "bubbles & stalls".

So it is not VMT the problem, since its not only decode that is VMT... its fetch, branch, dispatch including the "FlexFPU frontend". The decode problem can be fixed by relaxing the "dependency" checking and constrains upon decoding complex operations (2 "independent" complex operations, forcingly upon 2 thread contexts) .. MOAR = brute force, always leads to disappointing results.

VMT is so nice... and since a "module" is an optimized 2 cores sharing... that is, another CPU core "jumped inside" another core to make a module, that in the future i see a "module" jumping inside another module (sharing) to make a 4 core/thread module lol

I also see VMT use in a "Horizontal" way... so Horizontal Multi-Threading using the same "asynchronous open contexts" of the VMT( in an horizontal way) and each Cluster ( integer core) have more than 1 thread context, yet not being SMT(simultaneous multi-threading) but an evolution of the CMT (cluster multi-threading) concept.

[ UPDATE: in actually the scheme of of BD/PD is... A ->B -> A ->B -> ... its "interleaving", its one thread one cycle the other thread the other cycle, being the beauty of VTM that you have more fine grain control on the execution, i.e., it can be A->A->A->A->B ->B -> B -> B ... or any granularity between 1 and 4 instructions...

SteamRoller changes this to A-A ->B-B->A-A-> ... that is the "minimal granularity" passes to be " 2 instructions" in any combination up to 4( can be AAAA or BBBB)... it simplifies it, and probably wastes less power on context switches, and has no adverse effect on performance...

So the advantage of VMT over SMT is exactly the possibility of sharing resources having a fine-grain control, upon cache misses or other events, one thread never clogs the other , contrary to SMT/Hyperthreading that had to have resources augmented since Nehalem, since it was often that with SMT/HT turned off, the performance was greater than with SMT/HT on!

On VMT this is way much better (ok it doesn't approach the performance of 2 separated cores... but NOTHING will...)... if a thread just grabs all resources (and even waiting on instructions and or data can grab resources, that is, doing nothing can grab resources lol) then the VMT control can simply switch to another, it leads to much more efficient utilization of resources ]

These are the IPC improvement modifications for steamroller:

•Store to load forwarding optimization
•Dispatch and retire up to 2 stores per cycle
•Improved memfile, from last 3 stores to last 8 stores, and allow tracking of dependent stack operations.
•Load queue (LDQ) size increased to 48, from 44.
•Store queue (STQ) size increased to 32, from 24.
•Increase dispatch bandwidth to 8 INT ops per cycle (4 to each core), from 4 INT ops per cycle (4 to just 1 core). 4 ops per cycle per core remains unchanged.
•Accelerate SYSCALL/SYSRET.
•Increased L2 BTB size from 5K to 10K and from 8 to 16 banks.
•Improved loop prediction.
•Increase PFB from 8 to 16 entries; the 8 additional entries can be used either for prefetch or as a loop buffer.
•Increase snoop tag throughput.
•Change from 4 to 3 FP pipe stages.

Taken from this article:

http://www.brightsideofnews.com/news/2013/3/6/analysis-amd-kaveri-apu-and-steamroller-core-architectural-enhancements-unveiled.aspx

Given what they're talking about there, the interdependency constraints will be slightly more relaxed, the pipelines will be increased, and the prefetch increased as well. Plus with double the dispatch bandwidth, they actually will be able to feed the cores faster...

It looks good.



[juanrga]

I know this is an oversimplification but could this partially explain why 4C/8C Piledriver are being replaced by 2C/4C Steamroller?

My guess is that the 2M/4C Steamroller die is the "most commonly used" die and is inexpensive to make, since it is being used in laptop, mainstream desktop, and 1P server. AMD is seeming to take a page from Intel and introduce the "small die" parts first and then later on come with the 2P/4P server-derived parts on a larger die (e.g. 2P is still on Sandy Bridge despite Haswell being released on desktop/mobile.)

Agree that 2M/4C comes first by those reasons.

My guess is that a future 8C Steamroller chip will replace 12C/16C Piledriver Warsaw CPUs in the 2P/4P servers. I suppose this will happen in 2015.

I see each Piledriver chip being replaced by a Steamroller with half the cores.

I think people shouldn't expect miracles from SR. Take the latest A10-6800K benchmarks and add 30% for best case scenario. That's the best the 4C SR APU will do.

It's a good jump but don't expect it to beat the higher clocked i5s. It should put a hurt on i3s though, which is it's actual competition price wise.

There are two estimations. The first from Hot chips 2012, which claims about a 30% over Piledriver. Using that the 4C SR APU will be at the level of performance of an i5 IB

4C SR APU ~ i5-3570k

The second from Feldman interview (June 2013), where he says that Steamroller core is twice faster than jaguar core. Using that the 4C SR APU will be at the level of performance of an i7 SB

4C SR APU ~ i7-2600

Of course this all refers to the CPU alone. The GPU will be very powerful (Kaveri GPU has more GFLOPs than the entire trinity CPU+GPU).

Moreover, the above computations ignore the role of HSA. If half of the CUs are used for compute I would wait a performance boost of about 5x. Precisely developers "are seeing five times the performance" {*}

http://www.expertreviews.co.uk/processors/1299913/the-big-interview-apus-hsa-and-where-next-for-amd

{*} With HSA enabled software kaveri is years ahead of a i7-3930k



[szatkus]

There are two estimations. The first from Hot chips 2012, which claims about a 30% over Piledriver. Using that the 4C SR APU will be at the level of performance of an i5 IB

4C SR APU ~ i5-3570k

You mean this? http://assets.vr-zone.net/17088/AMD_SteamrollerServer.jpg
+30% more "ops delivered per cycle". But it's about FPU, not IPC of the whole module.

The second from Feldman interview (June 2013), where he says that Steamroller core is twice faster than jaguar core. Using that the 4C SR APU will be at the level of performance of an i7 SB

4C SR APU ~ i7-2600

Of course this all refers to the CPU alone. The GPU will be very powerful (Kaveri GPU has more GFLOPs than the entire trinity APU).

Moreover, the above computations ignore the role of HSA. If half of the CUs are used for compute I would wait a performance boost of about 5x.

Do you see there any "per clock"? Top clock for Jaguar core is ~2.0GHz, Bulldozer can easily achieve > 4.0GHz. Too imprecise to even call it "estimation".

There's excactly one meaningful estimation: http://www.tomshardware.co.uk/AMD-Kaveri-APU-Gaming,news-44336.html
+15-20% IPC. Seems realistic.



[GOM3RPLY3R]

With that 4C SR CPU being ~ i7-2600, which is HTed, wouldn't that mean that the per core performance would be greater on the SR CPU than the 2600? I hardly believe and ounce of that. It being anywhere from a low end i5 to a i5-3570k would be more reasonable. There's no way that AMD can pull off something where the per core performance doubles and it doesn't have the same, if not, higher price than the equivalent Intel CPU.

Even so it "exceeding an i7-3930k," the 3930k, if the right cooling option is added, can be OCed to 5.0 Ghz, but at an absolute max. If this chip can get near the power of the 3930k stock clock and vcore within the next year, I'd be very surprised.

I have to say, since AMD is able to throw less cores in the CPUs, I wonder what this means for the Heat and Power Consumption? :3



[juanrga]

A crazy idea

I read somewhat that one of main limitations of BD/PD modules was the single decode per module. If I understood this well, the decode switches between cores within a module which means cannot feed both cores in one clock. For a ten clock period, the situation would look like (A denotes first core working, B denotes second core working and _ denotes a core is not being feed)

A_
_B
A_
_B
A_
_B
A_
_B
A_
_B

Now Steamroller has twice decoders, which means each core can be feed in one clock

AB
AB
AB
AB
AB
AB
AB
AB
AB
AB

Each core in Steamroller module is being twice more efficient than in bulldozer/piledriver module, earning twice more instructions. To get the same number of A and B (10 each) one would use two bulldozer/piledriver modules

A_ A_
_B _B
A_ A_
_B _B
A_ A_
_B _B
A_ A_
_B _B
A_ A_
_B _B

I know this is an oversimplification but could this partially explain why 4C/8C Piledriver are being replaced by 2C/4C Steamroller?

wow!... an actual AMD uarch probably related Steamroller post, in a AMD uarch "expert" Steamroller thread ????? ... naa! i think "juanrga" is derailing the thread lol

elas!.. NO decode is not the main problem... it can be, depends on the software(compiler)... the problem with decode its the same as "If" a single core per "decode engine", that is if it were there only 1 integer core would be the same problem, i.e., in x86 the "complex" decode pipe blocks the others upon more complex instructions to decode, that is, upon more than 1 MacroOp( 2 microOPs, execute + memory), the 4 decode pipe acts like if it were only 1... the same thing happens with intel uarchs.(edt)

*IF* (not easy due to the "strong dependency model" of x86, which "a priori" sees every instruction dependent on another)... it was possible that upon decoding "complex" instructions the "complex decode pipe" doesn't block the others, the "same 4 decode" pipes would act like more 2 decode engines(or more) than else...

I think that is what happens with "Steamroller", it has the same 4 decode pipes of BD/PD, only perhaps instructions from one thread don't block instructions from the other thread, that is, Steamroller must have 2 "complex" decode pipes on those 4, that assume "non-dependent" instructions by checking the "contexts", and relax the dependency checking.

Yes... steamroller most probably will have the same 4 decode pipes of BD/PD... only arranged in a different fashion.

The question of "Vertical Multi-Threading" is not the culprit either, actually it is what makes it clearly superior to any intel uarch, that VMT works upon 2 "open contexts", that is, its incredible fast "internally changing the thread contexts" ( otherwise if it were OS dependent it would be slower than a Pentium I (quite slow) lol).. and the operation is inherently "asynchronous" (quite difficult).

VMT work like this.. .contexts can change from 1 cycle to another

AA or BB ... of course A_ or B_ or _ _ can happen... ( but there NEVER is AB or BA, that is SMT and no context changing needed) (edt)... but can happen also in STM (simultaneous multithreading = hyperthreading)... or in single cores... caches misses always leads to "bubbles & stalls".

So it is not VMT the problem, since its not only decode that is VMT... its fetch, branch, dispatch including the "FlexFPU frontend". The decode problem can be fixed by relaxing the "dependency" checking and constrains upon decoding complex operations (2 "independent" complex operations, forcingly upon 2 thread contexts) .. MOAR = brute force, always leads to disappointing results.

VMT is so nice... and since a "module" is an optimized 2 cores sharing... that is, another CPU core "jumped inside" another core to make a module, that in the future i see a "module" jumping inside another module (sharing) to make a 4 core/thread module lol

I also see VMT use in a "Horizontal" way... so Horizontal Multi-Threading using the same "asynchronous open contexts" of the VMT( in an horizontal way) and each Cluster ( integer core) have more than 1 thread context, yet not being SMT(simultaneous multi-threading) but an evolution of the CMT (cluster multi-threading) concept.

[ UPDATE: in actually the scheme of of BD/PD is... A ->B -> A ->B -> ... its "interleaving", its one thread one cycle the other thread the other cycle, being the beauty of VTM that you have more fine grain control on the execution, i.e., it can be A->A->A->A->B ->B -> B -> B ... or any granularity between 1 and 4 instructions...

SteamRoller changes this to A-A ->B-B->A-A-> ... that is the "minimal granularity" passes to be " 2 instructions" in any combination up to 4( can be AAAA or BBBB)... it simplifies it, and probably wastes less power on context switches, and has no adverse effect on performance...

So the advantage of VMT over SMT is exactly the possibility of sharing resources having a fine-grain control, upon cache misses or other events, one thread never clogs the other , contrary to SMT/Hyperthreading that had to have resources augmented since Nehalem, since it was often that with SMT/HT turned off, the performance was greater than with SMT/HT on!

On VMT this is way much better (ok it doesn't approach the performance of 2 separated cores... but NOTHING will...)... if a thread just grabs all resources (and even waiting on instructions and or data can grab resources, that is, doing nothing can grab resources lol) then the VMT control can simply switch to another, it leads to much more efficient utilization of resources ]

Yeah, there are rumours I am going to be banned by posting on-topic, he he.

By the above

A_
_B
A_
_B
...

I did mean your "A ->B -> A ->B -> ..."

Now I need time to decode what do you mean by "A-A ->B-B->A-A-> ..."



[The Q6660 Inside]

With that 4C SR CPU being ~ i7-2600, which is HTed, wouldn't that mean that the per core performance would be greater on the SR CPU than the 2600? I hardly believe and ounce of that. It being anywhere from a low end i5 to a i5-3570k would be more reasonable. There's no way that AMD can pull off something where the per core performance doubles and it doesn't have the same, if not, higher price than the equivalent Intel CPU.

Even so it "exceeding an i7-3930k," the 3930k, if the right cooling option is added, can be OCed to 5.0 Ghz, but at an absolute max. If this chip can get near the power of the 3930k stock clock and vcore within the next year, I'd be very surprised.

I have to say, since AMD is able to throw less cores in the CPUs, I wonder what this means for the Heat and Power Consumption? :3

I would assume the Steamroller Kaveri A10 APU is around i5 2550K CPU performance for the most part.



[cowboy44mag]

Juanrga:
"http://www.expertreviews.co.uk/processors/1299913/the-b...

{*} With HSA enabled software kaveri is years ahead of a i7-3930k "

Very interesting read, and I think it sums up what the difference in thinking between Intel fans and AMD fans when it comes to performance. Intel fans are still going by current and past ways of measuring performance where raw CPU power was the most important factor. AMD fans are looking to the future, with fully developed HSA applications, where the combined CPU/GPU power is what is important. The raw CPU power of an A10 Kaveri APU may only equal an i5 2550K, however when running HSA enabled applications its benchmarks will far surpass i7 4770K. It will all come down to what application you are running and what technology is being implemented as to what is more powerful Steamroller or Haswell. Intel will doubtless still have better benchmarks for the old standards of benchmarking, however Intel fans have an impossible time accepting that those benchmarking methods are going to become obsolete very soon.

We are no long interested in CPU performance alone, but CPU/GPU performance in HSA enabled applications (which we will be seeing more and more of). There are already some top notch companies in the HSA Foundation, and I expect many more to jump on board once its full potential is realized.



[The Q6660 Inside]

Juanrga:
"http://www.expertreviews.co.uk/processors/1299913/the-b...

{*} With HSA enabled software kaveri is years ahead of a i7-3930k "

Very interesting read, and I think it sums up what the difference in thinking between Intel fans and AMD fans when it comes to performance. Intel fans are still going by current and past ways of measuring performance where raw CPU power was the most important factor. AMD fans are looking to the future, with fully developed HSA applications, where the combined CPU/GPU power is what is important. The raw CPU power of an A10 Kaveri APU may only equal an i5 2550K, however when running HSA enabled applications its benchmarks will far surpass i7 4770K. It will all come down to what application you are running and what technology is being implemented as to what is more powerful Steamroller or Haswell. Intel will doubtless still have better benchmarks for the old standards of benchmarking, however Intel fans have an impossible time accepting that those benchmarking methods are going to become obsolete very soon.

We are no long interested in CPU performance alone, but CPU/GPU performance in HSA enabled applications (which we will be seeing more and more of). There are already some top notch companies in the HSA Foundation, and I expect many more to jump on board once its full potential is realized.

+1



[GOM3RPLY3R]

I was wondering what to post for a little bit, as there was nothing I could really build on. But I thought I would bring to attention this:

It's a music generation software made by Yamaha that uses real actresses voices to create songs. The actresses sing (more or less), all the vowels in Japanese, then they can be used at ~ any pitch to make a song. I thought this would be nice to add since it is a pretty CPU dependent, as with my Core 2 Quad @ 2.5 Ghz (idles @ 40-50 % usage), gets ramped up to 90-100% easily just by putting a few measures of voice in. I think that running it, and audio encoding would be a great benchamarking tool.

Otherwise, it's pretty neat software. I'm actually recreating a song from an anime that I watched (Kobato). The song is Ashita Huru Hi, its a nice song. Thus far, 8 measures in, the lyrics ~ sound exactly like they're pronounced (with the exception of a few vowels), and the pitches are spot on. ^_^

Hatsune Miku, the most famous Vocaloid Actress:



[cowboy44mag]

lol, hsa is a bit like intel quick sync in certain aspects. Quickens the time to do a task compared to the cpu but quick sync I find encoding is rubbish compared to cpu only. I can record games with action though with quick sync very good. Anyway this hsa is a load of nonsense for real world applications most people will use.

Intel has nothing like HSA. Intel is not interested in developing true APUs, not to mention their attempt with Haswell integrated GPUs isn't fairing so well now is it. Companies take one look at Haswell and put dedicated graphics solutions in them.

HSA has so much potential that it is truly mind blowing. IF you bothered to read the the linked article you would see that software applications with HSA support are showing 500% improvement. I believe that Haswell was a 10% improvement at best, more like 6% real world.

Simply put take a look at the HSA Foundation. Those companies are no "joke", and they wouldn't be supporting HSA development if it were a joke.



[griptwister]

Tomshardware: Intel v.s AMD

Here you guys go. Sorry that it posted twice, I need to get the other removed, this is the original.

Don't know how it goes but i posted a very educated comment.

Me too! Ahahaha!



[griptwister]

lol, hsa is a bit like intel quick sync in certain aspects. Quickens the time to do a task compared to the cpu but quick sync I find encoding is rubbish compared to cpu only. I can record games with action though with quick sync very good. Anyway this hsa is a load of nonsense for real world applications most people will use.

Considering HSA is faster than quick sync. Your quoted post was a load of nonsense. And all those Intel benchmarks you posted are also under this category are a load of non-sense.

(I still have no Idea why we feed this guy)



[szatkus]

But you know that x5 boost is the best case scenario? It highly depends on type of computation. There's plenty of algorithms for which a performance boost could be much smaller.

BTW. QuickSync is competing with OpenCL, not HSA. HSA is just hardware feature which can be used by OpenCL.



[juanrga]

There are two estimations. The first from Hot chips 2012, which claims about a 30% over Piledriver. Using that the 4C SR APU will be at the level of performance of an i5 IB

4C SR APU ~ i5-3570k

You mean this? http://assets.vr-zone.net/17088/AMD_SteamrollerServer.jpg
+30% more "ops delivered per cycle". But it's about FPU, not IPC of the whole module.

The second from Feldman interview (June 2013), where he says that Steamroller core is twice faster than jaguar core. Using that the 4C SR APU will be at the level of performance of an i7 SB

4C SR APU ~ i7-2600

Of course this all refers to the CPU alone. The GPU will be very powerful (Kaveri GPU has more GFLOPs than the entire trinity APU).

Moreover, the above computations ignore the role of HSA. If half of the CUs are used for compute I would wait a performance boost of about 5x.

Do you see there any "per clock"? Top clock for Jaguar core is ~2.0GHz, Bulldozer can easily achieve > 4.0GHz. Too imprecise to even call it "estimation".

There's excactly one meaningful estimation: http://www.tomshardware.co.uk/AMD-Kaveri-APU-Gaming,news-44336.html
+15-20% IPC. Seems realistic.

I did mean this

You are right on that Feldman does not say per clock, but neither he says 4GHz vs 2.0GHz.

Imagine that you are right and he did mean Steamroller 4GHz is twice faster than Jaguar 2Ghz (which is a rather trivial statement), then Steamroller would be about the same than Jaguar per clock and I would correct my estimation by a x0.5 factor. The conclusion being that Kaveri 4C would be slower than trinity 4C. Congrats!

I think that Feldman did mean per clock, and using that I obtain the i7 SB level, which is close to the i5 IB level obtained with the 30% IPC.

With that 4C SR CPU being ~ i7-2600, which is HTed, wouldn't that mean that the per core performance would be greater on the SR CPU than the 2600? I hardly believe and ounce of that. It being anywhere from a low end i5 to a i5-3570k would be more reasonable. There's no way that AMD can pull off something where the per core performance doubles and it doesn't have the same, if not, higher price than the equivalent Intel CPU.

Even so it "exceeding an i7-3930k," the 3930k, if the right cooling option is added, can be OCed to 5.0 Ghz, but at an absolute max. If this chip can get near the power of the 3930k stock clock and vcore within the next year, I'd be very surprised.

I have to say, since AMD is able to throw less cores in the CPUs, I wonder what this means for the Heat and Power Consumption? :3

The 2600 has poor per core performance than the 3570k. My above estimations were for multithreaded scenarios (that is why the 2600 scores higher than the 3500k), because this is what is more important for real use for most people.

Even if the 3930k could be OC up to 8 GHz (which I doubt) using extreme cooling, it couldn't compete with the performance of a HSA enabled chip offering a 500% boost at stock clocks. And don't forget that kaveri can be overclocked as well, which would increase the gap.



[juanrga]

I would assume the Steamroller Kaveri A10 APU is around i5 2550K CPU performance for the most part.

A safe estimation. To add that the difference between the 3570k and the 2550k is of about a 10%.

Juanrga:
"http://www.expertreviews.co.uk/processors/1299913/the-b...

{*} With HSA enabled software kaveri is years ahead of a i7-3930k "

Very interesting read, and I think it sums up what the difference in thinking between Intel fans and AMD fans when it comes to performance. Intel fans are still going by current and past ways of measuring performance where raw CPU power was the most important factor. AMD fans are looking to the future, with fully developed HSA applications, where the combined CPU/GPU power is what is important. The raw CPU power of an A10 Kaveri APU may only equal an i5 2550K, however when running HSA enabled applications its benchmarks will far surpass i7 4770K. It will all come down to what application you are running and what technology is being implemented as to what is more powerful Steamroller or Haswell. Intel will doubtless still have better benchmarks for the old standards of benchmarking, however Intel fans have an impossible time accepting that those benchmarking methods are going to become obsolete very soon.

We are no long interested in CPU performance alone, but CPU/GPU performance in HSA enabled applications (which we will be seeing more and more of). There are already some top notch companies in the HSA Foundation, and I expect many more to jump on board once its full potential is realized.

Thanks. I also considered it very interesting. Note that the i7-4770k is not a HSA chip, but even if it was a fully enabled HSA chip it couldn't compete with kaveri under HSA software, because the 4770k has a total (CPU+GPU) of 848 GFLOPs, whereas kaveri 4C has a total (CPU+GPU) of 1052 GFLOPs.

I don't know now the performance of the iGPU of the 3770k but the total (CPU+GPU) has to be of less than 624 GFLOPs. More exactly 624 minus the GFLOPS between the HD4600 and the HD4000.

Your point about old benchmarks/apps versus new is perfect! I found this slide which gives a good idea of the tendency towards using the true performance of APUs



[szatkus]

I think that Feldman did mean per clock, and using that I obtain the i7 SB level, which is close to the i5 IB level obtained with the 30% IPC.

But Jaguar is already quite close to Piledriver. Double performance per clock would be just impossible. Even +30% IPC is too big (no one did that big jump in last 10 years) to be possible. Also I think that information from last month (+15-20%) are more reliable than some slide from last year.



[juanrga]

But you know that x5 boost is the best case scenario? It highly depends on type of computation. There's plenty of algorithms for which a performance boost could be much smaller.

The interview does not say "up to" or "best case scenario". But, at the same time, we don't wait 5x for any application. In fact, it would be ridiculous to wait 5x when typing in a word processing. The GPU play no role and the current performance of CPUs is more than enough for that task.

HSA is just hardware feature which can be used by OpenCL.

HSA is more than that. Toms has an article discussing HSA and OpenCL.



[szatkus]

But you know that x5 boost is the best case scenario? It highly depends on type of computation. There's plenty of algorithms for which a performance boost could be much smaller.

The interview does not say "up to" or "best case scenario". But, at the same time, we don't wait 5x for any application. In fact, it would be ridiculous to wait 5x when typing in a word processing. The GPU play no role and the current performance of CPUs is more than enough for that task.

It's obvious. 400% is much more than any estimation I saw earlier (not by AMD but done by some developers). It's possible to get so large boost, but in very rare cases. They just took the biggest number.

HSA is just hardware feature which can be used by OpenCL.

HSA is more than that. Toms has an article discussing HSA and OpenCL.

You're right it's also buzz-word.

Seriously, HSA is invisible for developer. OpenCL was designed with shared pointers in mind. It will just work faster on HSA-capable hardware.



[gamerk316]

At the risk of igniting a firestorm:

1: The official 7-zip build is compiled by MSVC, not ICC.

2: From S/A:

http://semiaccurate.com/2013/07/15/company-of-heroes-2-relic-performance/

For those of you debating building a new system optimized specifically for playing this game, Relic told us that Company of Heroes 2 is much more likely to be CPU-bound, rather than GPU-bound. Apparently the Essence engine supports the use of up to eight threads simultaneously. But all the threads being run on those cores at some point have to come back and finish executing on the first core. Thus single threaded performance is very important according to Relic.

*whistles*



[simon12]

COH2 is interesting it doesn't like dual cores but the FX x3xx are all close and the 6 core intels are beaten by the quad i5s & i7s despite the i7s beating the i5s. The Phenom x4 stands up well for its age/price.

from http://www.techspot.com/review/689-company-of-heroes-2-performance/page4.html



[8350rocks]

But you know that x5 boost is the best case scenario? It highly depends on type of computation. There's plenty of algorithms for which a performance boost could be much smaller.

The interview does not say "up to" or "best case scenario". But, at the same time, we don't wait 5x for any application. In fact, it would be ridiculous to wait 5x when typing in a word processing. The GPU play no role and the current performance of CPUs is more than enough for that task.

It's obvious. 400% is much more than any estimation I saw earlier (not by AMD but done by some developers). It's possible to get so large boost, but in very rare cases. They just took the biggest number.

HSA is just hardware feature which can be used by OpenCL.

HSA is more than that. Toms has an article discussing HSA and OpenCL.

You're right it's also buzz-word.

Seriously, HSA is invisible for developer. OpenCL was designed with shared pointers in mind. It will just work faster on HSA-capable hardware.

Well, you're only partially right, OpenCL did imagine using shared pointers at some point, and GPUs doing general compute.

However, HSA goes a step farther, HSA enabled GPUs have the capability to use the GPU as a GPGPU when necessary on a much larger scale, where as OpenCL capable GPUs have fewer compute pipelines. Look at PS4, which is HSA enabled...it has 8x as many compute pipelines as the next best GPU Compute capable card out there...(HD 7990 has 8 compute pipelines, HD 7970 has 4).

So, it isn't just an expansion of OpenCL, but it's really moving in a forward direction ahead of what OpenCL originally envisioned/foresaw.

EDIT: Think of it like this, HSA is OpenCL in the same way that a house is a bathroom because it contains one...



[szatkus]

But you know that x5 boost is the best case scenario? It highly depends on type of computation. There's plenty of algorithms for which a performance boost could be much smaller.

The interview does not say "up to" or "best case scenario". But, at the same time, we don't wait 5x for any application. In fact, it would be ridiculous to wait 5x when typing in a word processing. The GPU play no role and the current performance of CPUs is more than enough for that task.

It's obvious. 400% is much more than any estimation I saw earlier (not by AMD but done by some developers). It's possible to get so large boost, but in very rare cases. They just took the biggest number.

HSA is just hardware feature which can be used by OpenCL.

HSA is more than that. Toms has an article discussing HSA and OpenCL.

You're right it's also buzz-word.

Seriously, HSA is invisible for developer. OpenCL was designed with shared pointers in mind. It will just work faster on HSA-capable hardware.

Well, you're only partially right, OpenCL did imagine using shared pointers at some point, and GPUs doing general compute.

However, HSA goes a step farther, HSA enabled GPUs have the capability to use the GPU as a GPGPU when necessary on a much larger scale, where as OpenCL capable GPUs have fewer compute pipelines. Look at PS4, which is HSA enabled...it has 8x as many compute pipelines as the next best GPU Compute capable card out there...(HD 7990 has 8 compute pipelines, HD 7970 has 4).

So, it isn't just an expansion of OpenCL, but it's really moving in a forward direction ahead of what OpenCL originally envisioned/foresaw.

I was talking from software perspective. On hardware level it's completly different from traditional GPGPU.



[8350rocks]

Only in the sense that the HSA enabled GPU can be dynamically used for compute and graphics, where as GPGPUs cannot be used for graphics.



[gamerk316]

Only in the sense that the HSA enabled GPU can be dynamically used for compute and graphics, where as GPGPUs cannot be used for graphics.

Sure they can! Granted, there's currently no way to funnel the DX/OGL API's to them, but nothing is stopping a developer from writing their own graphics implementation for use on a GPGPU.



[gamerk316]

COH2 is interesting it doesn't like dual cores but the FX x3xx are all close and the 6 core intels are beaten by the quad i5s & i7s despite the i7s beating the i5s. The Phenom x4 stands up well for its age/price.

from http://www.techspot.com/review/689-company-of-heroes-2-performance/page4.html

But again, look at the results by architecture generation: i3's hanging around with BD? Thats your per-core performance. The +8 FPS going from a 8150 to the 8350? Per core performance. The 20 extra FPS the 4770k gives you on top of that? Per-core performance. Heck, thats the reason the PII X4 is still hanging around (and really makes me wonder where a Q9650 would end up on the chart...)

So again: another game that uses 8+ threads, that performs better on quad core processors with higher per-core performance rather then the 8 core processor with lower per-core performance.
