Realistically It's a cheaper unit that is placed below it in the product stack, so really it doesn't surprise me they went with a cheaper platform.

Reminds me of how the Thermaltake Smart gold and white are completely different units, with the gold being a cost cut toughpower and the white being... Well you get the idea.

Darkbreeze said:
More ASUS BS. They just keep on coming up with reasons to stop trusting them, more every time you turn around.
Click to expand...

It doesn't matter, i bet it isn't going to work with Lovelace GPUs which would need more than 450W anyway, because it's Seasonic Prime.

It's too early to say if other PSUs would work either tho, there are 1.8kW transients in the standard. ASUS just wanted to out the first 'PCIe 5 compatible' PSU but as evident by this, didn't actually make sure that it is actually compatible, doesn't matter, it's just a marketing point until GPUs that need it would actually come out.

Last edited:
Right, but you can bet at least a moderate number of people have bought them with the idea in mind that later on they wouldn't have to buy another one, and probably will.

I mean, I'd be pretty pissed if I spent good money on a car that was supposed to get 50mpg average and in reality only got 38.

  • Like
Reactions: King_V
Hmm. I was automatically thinking the evga P3 to be superflower, but it was announced only last year, so surely that's not it. I haven't seen much from FSP in recent memory, so it could only be HEC or Andyson....unless they have another oem? I don't remember ever seeing any platinum HEC units though. Any knowledge on it? I really don't want another andyson tbh.

maxamillionfeettall said:
Hmm. I was automatically thinking the evga P3 to be superflower, but it was announced only last year, so surely that's not it. I haven't seen much from FSP in recent memory, so it could only be HEC or Andyson....unless they have another oem? I don't remember ever seeing any platinum HEC units though. Any knowledge on it? I really don't want another andyson tbh.
Click to expand...
It's HEC, new platform, no reviews.

Well, I had not heard about this problem but it's rather serious. An unexpected stumble by Seasonic. And usually his reviews are duplicated here at Tom's, so I wonder why this one is not.

www.techpowerup.com

Seasonic Prime Fanless 700 W Review

The Seasonic Prime Fanless 700 W certainly isn't cheap, priced at $265, but offers the unique capability of a completely noise-free operation thanks to a passive design. With over 93% efficiency, it is among the best we've ever seen, but there are also some issues.
www.techpowerup.com www.techpowerup.com

Karadjgne said:
Where's the rest of it? I'd hate to see a graph of the outputs, the ripple on that thing would be rediculous for long term use.
Click to expand...

Sadly, LTT didn't put it through proper testing (oscilloscope, ripple etc). Maybe next vid the release, has the test results in it.

But that much is certain that this unit, will never be able to output 3450W, since the C13/C14 plugs it uses, are limited to 240V at 10A, which means 2400W. <- This is max what it can pull from the wall. And when factoring in the efficiency as well (some obscure "90 Plus Platinum"), it may produce ~2000W only.

It's way obscure PSU. Still, it's a good watch to learn, how not to make PSUs. :)

Aeacus said:
Sadly, LTT didn't put it through proper testing (oscilloscope, ripple etc). Maybe next vid the release, has the test results in it.

But that much is certain that this unit, will never be able to output 3450W, since the C13/C14 plugs it uses, are limited to 240V at 10A, which means 2400W. <- This is max what it can pull from the wall. And when factoring in the efficiency as well (some obscure "90 Plus Platinum"), it may produce ~2000W only.

It's way obscure PSU. Still, it's a good watch to learn, how not to make PSUs. :)
Click to expand...
It can likely draw more than 2400w from the wall for awhile before anything happens. Breakers don't immediately trip above their rated current, they usually take awhile, but that time goes down the more you draw past the rating.

So I agree it won't do rated wattage but it is possible that it could provide a above what it should be able to deliver given the rating of the plug.

NightHawkRMX said:
It can likely draw more than 2400w from the wall for awhile before anything happens. Breakers don't immediately trip above their rated current, they usually take awhile, but that time goes down the more you draw past the rating.

So I agree it won't do rated wattage but it is possible that it could provide a above what it should be able to deliver given the rating of the plug.
Click to expand...
Yeah, in a house with a well defined electric system.

Now, combine this dumpster fire PSU with an older, marginal house....

rounakr94 said:
HCG extreme's are good but the HCG golds have some issue with the 3xxx series. Have seen atleast 10-15 HCG's melt out their pcie connectors
Click to expand...
Lot's of Antec units from the last few years, regardless of the platform they were based on, have been sort of borderline. So, no argument there. It does, as always, depend on the SPECIFIC unit in question. And that, as always too, is always the case. Always. LOL.

rounakr94 said:
HCG extreme's are good but the HCG golds have some issue with the 3xxx series. Have seen atleast 10-15 HCG's melt out their pcie connectors
Click to expand...

Jesus, why would that happen on a quality unit? Luckily for me that hasn't happened on any of my PSU's, I think I would have noticed that, Unlike back in the day before I bought quality units.
Like I said above, I've been running this EXTREME unit for about four years and it still going smooth, having set my RX Vega 64 to the 220Watt option and combined with the rest of my components CPU at 125watt and the like, I can game all night and day no problem, I wonder what kind of a response I would get should I run into any trouble before the 10years warranty is up.

I'm probably not nearly drawing what this unit [ ANTEC HCG GOLD EXTREME] is capable of or putting it in any kind of danger of melting anything.

In my other second pc with its lower priority I have an COOLERMASTER V 1000 Gold, witch has been running for roughly a year and a half 24/7 smoothly, both are 83amp, but for both I don't know what year they are manufactured.

At this point I'm wondering what unit might suit my needs in the future, but when the time comes I'll surely pickup something excellent again.

Last edited:
itrip said:
Jesus, why would that happen on a quality unit?
Click to expand...

There are lemons, even among the best. And for that reason, we have warranty.

As of melting connectors go, perhaps the manufacturing defect with the cables was the issue, rather than PSU itself. 🤔 This is easily prevented by using custom sleeved compatible cables. E.g from CableMod.

  • Like
Reactions: King_V
