Hi,

I have built a few PCs over the years, I built this one around 2010, and because its becoming a bit obsolete, time to build a new one with a complete overhaul, in the past I would recycle components, but this time I think I need to upgrade most things. I will only recycle the loudspeakers, mouse and keyboard.

the motherboard is the startpoint for building a PC, and this one's is by Gigabyte and is ATX.

I would firstly like advice as to which motherboard manufacturer, eg ones with more or better early startup facilities, eg ability to boot from USB drives. I also want ancient floppy disk support, because I have dabbled with writing software on floppy disks which boot directly without operating system. I dont know if all ATX's support the ancient floppy drives. Also a manufacturer whose motherboards are reliable.

this Gigabyte one has been good but after 13 years of use, the USB seems to sometimes malfunction for the wireless USB dongle, I think the USB support on the motherboard is somehow worn out. And eg hard drives attached to the USB hub attached to the machine will vanish.

I would also like legacy support for PS/2 mouse and keyboard, ie PS/2 sockets at the back for mouse and keyboard. Basically I want as much legacy hardware support as possible, as I have programmed PS2 mouse and keyboard directly for my floppy booting software. I know USB can emulate legacy, but I would like the legacy hardware directly.

Some months ago I bought a laptop with touchscreen and windows 11. I dont know if one can buy touchscreen monitors for PCs? Also can windows 10 support such, or does it have to be windows 11. As I would need to buy Windows also. I have some spare licensed copies of Windows 10 not yet installed, bought so they can be used when windows 10 is no longer supported.

Then advice on tower cases for the system, I would like a transparent one where I can see everything inside the machine without having to open up. But I would like one also which uses old school slotting, my existing one has nonstandard plastic things, which I find very confusing, and some have broken. I would like as many bays as possible, eg I have lots of SATA drives.

any advice on specific such tower cases, and specific UK vendors who sell these, I dont know if I am allowed to ask such advice on this forum. I found PC World no use for tower cases, and had problems finding anything any good on ebay.

with my existing machine, I found the expansion slots a bit cramped, where the graphics card is too near the slot I use for the USB3 adapter, I dont know if this is a limit of the ATX specification, or if it is a manufacturer design limitation. it would be nice if there were more space between the sockets.

This existing system, has various bare wire USB sockets on the motherboard, which I found a bit confusing to connect up, I would prefer proper USB sockets on the motherboard accessible at the back. But maybe all have this problem?

I think I would like DV-I and hdmi support, with my existing machine, its hdmi doesnt do audio, I dont know if newer machines have integrated audio into the hdmi, and what to look for to get hdmi with audio. that way I could record a session on the machine for say Youtube. I dont know if this is a graphics card question rather than a motherboard question, and if a graphics card question, advice on which graphics cards.


it is lots of questions, and the central question is which motherboard manufacturer, and the constraints of both ancient hardware eg floppies and ps/2 but also modern hardware eg touchscreens, which might constrain which version of windows or the graphics card etc.

with my touchscreen laptop, I found the early startup controls a bit limited, and it doesnt allow enough time for the external USB bluray drive to get ready to boot say Linux mint, I had to configure the hubs a certain way before I could get that to boot, which is a limitation of the early startup.

anyway, many thanks for any advice
Richard


USAFRet

Titan
Moderator
I wasnt aware of that!

so far I have just activated one win10 license, can I use that one also for win11 if I stop using the win10 installation?

I decided to buy a batch of licenses because with XP I wish I had bought up some when the next version of Windows was released, as that would be a really matured version of XP. the version I did have needed a separate SP2 (or was it SP3?) disk for some software to work, and I had to obtain one from the internet when I reinstalled the system, as the original install got updated via automatic updates.

where it would have been better to have bought a matured version of XP with that built in.

its a kind of insurance policy,
Yes, you can use an otherwise unused Win 10 license for a Win 11 install.

Whatever happened with XP is irrelevant. The licensing rules have changed significantly.

  • Like
Reactions: helper800

Aeacus

Titan
Ambassador
I dont know if you can give a full system involving the Ace including purchase links?
Like this?

PCPartPicker Part List

CPU: AMD Ryzen 9 7950X3D 4.2 GHz 16-Core Processor (£570.97 @ Amazon UK)
CPU Cooler: be quiet! Dark Rock Pro 5 CPU Cooler (£98.36 @ Amazon UK)
Motherboard: MSI MEG X670E ACE EATX AM5 Motherboard (£749.99)
Memory: Corsair Vengeance 64 GB (4 x 16 GB) DDR5-6400 CL32 Memory (£256.49 @ Amazon UK)
Storage: Samsung 990 Pro 2 TB M.2-2280 PCIe 4.0 X4 NVME Solid State Drive (£169.99 @ Amazon UK)
Case: Phanteks Enthoo Pro Tempered Glass ATX Full Tower Case (£124.95 @ Amazon UK)
Power Supply: SeaSonic PRIME TX-1600 ATX 3.0 1600 W 80+ Titanium Certified Fully Modular ATX Power Supply (£523.67)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Total: £2697.07

Prices include shipping, taxes, and discounts when available
Generated by PCPartPicker 2024-01-28 01:07 GMT+0000


Purchase links that pcpp doesn't have;
MoBo: https://www.amazon.co.uk/MSI-MEG-X670E-Motherboard-ATX/dp/B0B6Q4X5NF/
PSU: https://www.amazon.co.uk/Seasonic-ATX-3-0-TX-1600-Titanium/dp/B0C571LRNB

The rest of the purchase links you can find when you click on the component name.

also the memory, was thinking of going for 64GB, I presume DDR5 is the best option, maybe the only option for this mobo?
It's not the MoBo, but instead CPU that only supports DDR5 RAM.

Like i said earlier, Ryzen 7000-series CPUs support only DDR5 RAM. If you want DDR4 RAM, then you have to replace CPU. Either Ryzen 5000-series or Intel.

also I would initially opt out of the GPU, but you could include that for future reference where I can subtract out that price for the current cost.
With GPU, things are difficult since i have no way of knowing how beefy of a GPU you require. Web browsing and smaller tasks can be done by iGPU inside the CPU. Dedicated GPU is needed for heavier graphical load, which you don't do. Playing videos isn't considered as heavy graphical load. Playing game and/or doing 3D render - is. So, due to that, i can't suggest if you should go with RTX 4060 (~£300) or up to RTX 4090 (~£2200). But the PC is currently configured as such, that you can go with any GPU you desire.

as regards the memory speed, I dont want to pay a huge amount extra just to get a small speed increase, and I wont ever be overclocking, I use everything within the official limits, as that way I am covered by all guarantees.
For the build above, i put in 4x 16GB 6400 Mhz RAM with CAS Latency of 32. This means that the RAM latency is 10 nanoseconds, with is really good. Price difference between this and cheapest 4x 16GB set is ~£35. Cheaper RAM has slower frequency (6000 Mhz vs 6400 Mhz) and higher CAS Latency (CL36 vs CL32).
Cheapest RAM pcpp: https://uk.pcpartpicker.com/product...6-gb-ddr5-6000-cl36-memory-cmk64gx5m4b6000z36

So, for as little as 35 quid, getting both faster and more responsive RAM is better.


Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
Like this?

PCPartPicker Part List

CPU: AMD Ryzen 9 7950X3D 4.2 GHz 16-Core Processor (£570.97 @ Amazon UK)
CPU Cooler: be quiet! Dark Rock Pro 5 CPU Cooler (£98.36 @ Amazon UK)
Motherboard: MSI MEG X670E ACE EATX AM5 Motherboard (£749.99)
Memory: Corsair Vengeance 64 GB (4 x 16 GB) DDR5-6400 CL32 Memory (£256.49 @ Amazon UK)
Storage: Samsung 990 Pro 2 TB M.2-2280 PCIe 4.0 X4 NVME Solid State Drive (£169.99 @ Amazon UK)
Case: Phanteks Enthoo Pro Tempered Glass ATX Full Tower Case (£124.95 @ Amazon UK)
Power Supply: SeaSonic PRIME TX-1600 ATX 3.0 1600 W 80+ Titanium Certified Fully Modular ATX Power Supply (£523.67)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Case Fan: Noctua A14 industrialPPC-2000 107.42 CFM 140 mm Fan (£28.95 @ Amazon UK)
Total: £2697.07

Prices include shipping, taxes, and discounts when available
Generated by PCPartPicker 2024-01-28 01:07 GMT+0000


Purchase links that pcpp doesn't have;
MoBo: https://www.amazon.co.uk/MSI-MEG-X670E-Motherboard-ATX/dp/B0B6Q4X5NF/
PSU: https://www.amazon.co.uk/Seasonic-ATX-3-0-TX-1600-Titanium/dp/B0C571LRNB

The rest of the purchase links you can find when you click on the component name.
many thanks for the config, will start purchasing over the next few days.


It's not the MoBo, but instead CPU that only supports DDR5 RAM.

Like i said earlier, Ryzen 7000-series CPUs support only DDR5 RAM. If you want DDR4 RAM, then you have to replace CPU. Either Ryzen 5000-series or Intel.
they have probably optimised for the faster memory technology,

eg maybe the DDR4 with that CPU wouldnt make sense in some way, like buying a palace and then using linos for the flooring.




With GPU, things are difficult since i have no way of knowing how beefy of a GPU you require. Web browsing and smaller tasks can be done by iGPU inside the CPU. Dedicated GPU is needed for heavier graphical load, which you don't do. Playing videos isn't considered as heavy graphical load. Playing game and/or doing 3D render - is. So, due to that, i can't suggest if you should go with RTX 4060 (~£300) or up to RTX 4090 (~£2200). But the PC is currently configured as such, that you can go with any GPU you desire.

lets say I go for dual GPU, presumably I buy 2 identical GPUs, where the £300 becomes £600, and the £2200 becomes £4400?

could you compare and contrast say a few across the spectrum from the £300 to the £2200

eg say a further 2 at maybe £1000 and £1500.

if there is an RTX 4060 and an RTX 4090, by continuity of the numbers there could be an RTX 4070, and an RTX 4080?


I would say £4400 is getting too expensive, because for that price range, I ought to then get the Godlike, and even consider getting the $9999=£7800 cpu, a problem of proportionality. could be better just to get the threadripper and not bother with the GPUs.

would that threadripper cpu work with the Ace?
would it work with the rest of that config? or do various things need rethinking? eg the cooling and PSU might be insufficient.


and were I to consider that, I would rather start with a less powerful system in order to calibrate more precisely what I need. eg to get the Ace + £570 cpu based system, then later on in time, go for very carefully selected higher end config. on a need-to-buy basis.

I follow the principle that the more expensive something is, the more research you should do and you need to be more sure you will use the extra facilities. its often best to gradually increase specification.

sometimes I go for lowest end possible first, in order to learn what I really want. when I try new foods, I usually go for the cheapest possible size, even if its the worst value, because often I wont like the food, and the value for money is irrelevant, the big problem is the total price. eg if they say buy 1, £1, buy 2 £1.50, I will just buy the 1, as it may be rubbish. but once I know its good I might buy 8 for £5. my first PC was a cheapest possible HP Pavilion, from which I gradually learnt all the reasons I shouldnt have bought that! eg windows is built in, whereas with a homebuilt PC, you can reinstall the standalone Windows to a new build. same problem with the preinstalled software, you cant reinstall that to a new PC. the optical drive was cheap rubbish.


what would I gain by getting an RTX 4090 rather than a RTX 4060?

and in what circumstances would there be a noticeable improvement?

eg if one went from 100 frames per second, to 200, its a big improvement but isnt noticeable!

its a bit like buying a 300mph car, when the speed limit is 70mph, and you'd need a specially designed road to do 300mph because of reaction time and imprecision. faster roads curve less where you only turn the steering wheel by subtle amounts.

industrial grade systems are generally only appropriate for industrial grade usages, eg if you buy a lorry, you wont be able to go to the normal car washes, and will have problems parking the lorry when you go shopping, and it wont fit in your garage at home. and it will be work to load the shopping into the back of the lorry. also you now have to watch out for height and weight restrictions. and then the insurance.
most of the time, most of the lorry will be empty: better to just hire a lorry on the few occasions you need the extra capacity.

I regard the $9999 cpu as kind of going shopping with a lorry.


For the build above, i put in 4x 16GB 6400 Mhz RAM with CAS Latency of 32. This means that the RAM latency is 10 nanoseconds, with is really good. Price difference between this and cheapest 4x 16GB set is ~£35. Cheaper RAM has slower frequency (6000 Mhz vs 6400 Mhz) and higher CAS Latency (CL36 vs CL32).
Cheapest RAM pcpp: https://uk.pcpartpicker.com/product...6-gb-ddr5-6000-cl36-memory-cmk64gx5m4b6000z36

So, for as little as 35 quid, getting both faster and more responsive RAM is better.
what would be the top end way to do say 64GB where the rest of the config the same?

what would be the top end way to do 32GB, versus the 4 x 16GB 6400 Mhz that you gave?

both in terms of price and speeds.


which are the circumstances that 32GB wont be enough? eg you could fit an entire bluray disk in 32GB as I think those are 25GB (unless you go for dual layer).


and what kind of cost for the max memory of 192GB? eg what is the low end cost and top end cost for the full 192GB? just to get some perspective of this aspect of the config.


35below0

Respectable
Jan 3, 2024
1,727
744
2,090
I wasnt aware of that!

so far I have just activated one win10 license, can I use that one also for win11 if I stop using the win10 installation?

I decided to buy a batch of licenses because with XP I wish I had bought up some when the next version of Windows was released, as that would be a really matured version of XP. the version I did have needed a separate SP2 (or was it SP3?) disk for some software to work, and I had to obtain one from the internet when I reinstalled the system, as the original install got updated via automatic updates.

where it would have been better to have bought a matured version of XP with that built in.

its a kind of insurance policy,
AFAIK only OEM licenses are tied to a specific computer, or rather it's motherboard.

I wanted to check whether you know that you don't need to go buying win 11 licenses because you've already got them. :)
Even if your existing win 10 license is not transferable for any reason, microsoft never changed the licenses after win 11 came out, so they are basicaly compatible. A win 10 license can unlock win 11, and vice versa.

I had a Win 11 license but could not install win 11 due to a faulty install stick.
So i made a win 10 install USB with the win 10 ISO downloaded from microsoft, installed win 10, licensed it with the license that came with the win 11 package, then upgraded to 11 through the updates menu of win 10. (i purchased win 11 in a reputable store, for ~$145. wasn't fake, just a dud stick)


USAFRet

Titan
Moderator
I had a Win 11 license but could not install win 11 due to a faulty install stick.
So i made a win 10 install USB with the win 10 ISO downloaded from microsoft, installed win 10, licensed it with the license that came with the win 11 package, then upgraded to 11 through the updates menu of win 10.
You could have made your own Win 11 USB, direct from MS.
Install, and apply that license you bought.
No Win 10 needed.


35below0

Respectable
Jan 3, 2024
1,727
744
2,090
You could have made your own Win 11 USB, direct from MS.
Install, and apply that license you bought.
No Win 10 needed.
Yes, but because of the trouble i had with the win 11 installer, i chose to play it safe and upgrade from 10 using a Rufus made USB.

For one, win 11 is more picky about hardware. Even though my hardware exceeded minimums, setup didn't see it that way. And that setup looked like a hacked win 95 setup microsoft kept alive in a jar or formaldehyde. Came in a modern box on a modern USB but it's still the same old, same old.
All it did was state the machine fails to meet requirements and give me a link to said requirements. No idea which one i failed to meet. (it's obvious now it was not recognising secure boot, but i really don't want to veer so far off topic)

Secondly, installing win 10 would give me a usable OS. The PC was brand new so staring at fans spinning in UEFI was about all i could do with it.

Finally, upgrading from win 10 uses a different program, and one that is more helpful. It reported all system requirements in full detail and was happy to perform the upgrade. It was quite easy and even though it used to be preferable to make a clean install, i'm not so sure that applies to win 11.

I really tried everything to get that official 11 install USB to work. After having to reach for the screwdriver to clear CMOS for the third time, enough was enough and all i wanted was a safe and bootable USB. Win 10 setup was also guaranteed not to hiccup over secure boot, so there's that too.

One unusual unexpected thing worth mentioning is that the upgrade to Win 11 wasn't offered immediately. It only appeared after a few days.

Last edited:

Aeacus

Titan
Ambassador
I've not been following this whole thing, but WHY 2x GPU?
What is the specific use case here?
The MoBo OP is going for, has AMD multi-GPU support and i've explained to OP what it is and use cases where one would use two GPUs. Namely for workstation use, by spreading the load between two GPUs (helpful in 3D render projects). Due to that, multi-GPU is one option that OP can go for, if they have a need for it.

lets say I go for dual GPU, presumably I buy 2 identical GPUs, where the £300 becomes £600, and the £2200 becomes £4400?

could you compare and contrast say a few across the spectrum from the £300 to the £2200

eg say a further 2 at maybe £1000 and £1500.
Do note that you can't use two RTX 4090 GPUs in this system since PSU is way too weak to run two RTX 4090 GPUs. It is enough for one RTX 4090. Going with 2kW PSU should suffice, or when you get 2nd PSU just to power 2nd RTX 4090. Still, with the price of one RTX 4090, not worth to use two in the same system. In workstation usage, Nvidia Quadro would be far better option. Like RTX 6000 Ada Generation,
Nvidia: https://store.nvidia.com/en-us/nvidia-rtx/store/?page=1&limit=9&locale=en-us

If you do like to end up using multiple-GPU setup, i suggest going with Quadro instead. GeForce GPUs are designed for gaming use, while Quadro GPUs are designed for workstation use.

In a nutshell:
GeForce/Radeon - jack of all trades, master of one (gaming).
Quadro/Radeon Pro (FirePro) - jack of all trades, master of all but one (everything else, except gaming).

Further reading and to help you decide between workstation or gamer GPU,
link: https://www.gpumag.com/nvidia-quadro-vs-geforce/

I suggest that you read it. It's nice article. :)

if there is an RTX 4060 and an RTX 4090, by continuity of the numbers there could be an RTX 4070, and an RTX 4080?
Yes, there are and actually several variants as well;
4060 series = 4060, 4060 Ti 8GB, 4060 Ti 16GB,
4070 series = 4070, 4070 Super, 4070 Ti, 4070 Ti Super
4080 series = 4080, 4080 Super
4090 series = 4090

"Super" cards are actually the latest releases, released a day ago or so.

would that threadripper cpu work with the Ace?
No.

Latest Threadripper CPUs, 7000-series, are using sTR5 CPU socket.
Further reading: https://en.wikipedia.org/wiki/List_..._Peak_(Threadripper_7000_series,_Zen_4_based)

Price is also hefty per CPU;
7960X - $1499 USD
7970X - $2999 USD
7980X - $4999 USD

While Threadripper Pro CPUs are still TBA (To Be Announced).

would it work with the rest of that config? or do various things need rethinking? eg the cooling and PSU might be insufficient.
Different MoBo and CPU cooler is a must. PSU will do fine, since all 7000-series Threadripper and Threadripper Pro CPUs are rated for 350W.

what would I gain by getting an RTX 4090 rather than a RTX 4060?
Far more GPU compute power. Also, higher power consumption and more heat produced as well. Oh, GPU itself (physical size) is also larger, namely due to the cooler it has on it.

and in what circumstances would there be a noticeable improvement?
Since GeForce GPUs are designed for gaming, you'd get more FPS (Frames Per Second) with RTX 4090 than with RTX 4060. Quite a bit more actually.
Comparison: https://www.topcpu.net/en/gpu-c/NVIDIA-GeForce-RTX-4060-vs-NVIDIA-GeForce-RTX-4090

Tech specs:

GPU nameRTX 4060RTX 4090
Pipelines / CUDA cores307216384
Core clock speed1830 MHz2235 MHz
Boost clock speed2460 MHz2520 MHz
Number of transistors35,800 million76,300 million
Manufacturing process technology5 nm5 nm
Power consumption (TDP)115 Watt450 Watt
Texture fill rate236.21,290
Memory typeGDDR6GDDR6X
Maximum RAM amount8 GB24 GB
Memory bus width128 Bit384 Bit
Memory clock speed17000 MHz21000 MHz
Memory bandwidth272.0 GB/s1,008 GB/s
Shared memory--

Depending on a resolution and game in question, RTX 4090 is anywhere between 80% up to 420% better than RTX 4060.
But this only matters if you play games. If you do not, it matters little in terms of FPS these GeForce GPUs produce. And as i said earlier, if you'd need GPU for 3D render or number cruncing, Quadro is far better choice. One thing that Quadro GPUs have, over gaming (GeForce) GPUs, is that all Quadro GPUs also have ECC VRAM.

eg if one went from 100 frames per second, to 200, its a big improvement but isnt noticeable!

its a bit like buying a 300mph car, when the speed limit is 70mph, and you'd need a specially designed road to do 300mph because of reaction time and imprecision. faster roads curve less where you only turn the steering wheel by subtle amounts.

industrial grade systems are generally only appropriate for industrial grade usages, eg if you buy a lorry, you wont be able to go to the normal car washes, and will have problems parking the lorry when you go shopping, and it wont fit in your garage at home. and it will be work to load the shopping into the back of the lorry. also you now have to watch out for height and weight restrictions. and then the insurance.
most of the time, most of the lorry will be empty: better to just hire a lorry on the few occasions you need the extra capacity.

I regard the $9999 cpu as kind of going shopping with a lorry.
It depends on your usage case of a CPU/GPU.

Sure, as a daily driver for groceries shopping, lorry is too much. But if you're in the business of moving stuff, small passenger car just doesn't cut it. Sure, you could hook small trailer behind it but passenger car still doesn't cut it compared to lorry. In this example, cargo van would be best option. But lorry can also be a good option if you look at it as an investment to the future, IF you expect your business to grow, whereby you are going to utilize the lorry at it's fullest.

In similar sense, buying Threadripper CPU or Quadro GPU is same. It's an investment for the future and not an expenditure for entertainment.

what would be the top end way to do say 64GB where the rest of the config the same?
Comparison, pcpp: https://uk.pcpartpicker.com/products/compare/HZLdnQ,xK88TW,8wyH99/

Three RAM kits are compared there;
1. the cheapest option i talked about (£220, 6000 Mhz, CL36, response time 12 nanoseconds),
2. the one i included in your build (£255, 6400 Mhz, CL32, response time 10 nanoseconds)
3. and the top end one (£390, 6600 Mhz, CL32, response time 9,697 nanoseconds).

Top end one isn't justified in price increase of £135 while only gaining 200 Mhz faster frequency, which at same CAS Latency, brings the response time from 10 nanoseconds down to 9,697 nanoseconds. Gain of 0,303 nanoseconds isn't worth the €130.
Cheapest option compared to what i included, has 400 Mhz less frequency and 2 nanoseconds longer response time, with a saving of only £35. So, at that price point, going with the one i included to the build, is cost effective.

what would be the top end way to do 32GB, versus the 4 x 16GB 6400 Mhz that you gave?
This, pcpp: https://uk.pcpartpicker.com/products/compare/mHYmP6,xQ8bt6,xK88TW/

Again, three RAM kits are compared there;
1. the one i included in your build (4x 16GB),
2. the one that has the fastest frequency (8000 Mhz) for 2x 16GB
3. and the one that has the shortest response time (9,231 nanoseconds) for 2x 16GB.

Now, the shortest response time 2x 16GB set does have 7800 Mhz frequency, gain of 1200 Mhz over 6400 Mhz kit i included and is 0,769 nanoseconds faster in terms of response time, while costing £48 less. But with this, you'll get only half of RAM amount, 32GB vs the one i included, 64GB.
Fastest frequency RAM, at 8000 Mhz, has gain of 1600 Mhz over the one i included, while also offering 0,5 nanoseconds faster response time. But it will cost £112 more than the one i included, while offering half the RAM capacity. So, not worth the buy.

Of course, RAM speeds faster than ~6600 Mhz always have the issue of not actually being able to run at so high frequency as they are rated for. Sure, RAM manufacturer has successfully tested the RAM to be stable at 7800/8000 Mhz and MoBo manufacturer has also tested that their MoBo can run RAM at 7800/8000 Mhz, but it is only select few RAM kits that can do that.

For example, MSI has tested that only 4 RAM kits are capable of running at 8000 Mhz on their Ace MoBo. Two are 48GB sets and other two are 32GB sets.
MSI Ace MoBo memory QVL: https://www.msi.com/Motherboard/MEG-X670E-ACE/support#mem

E.g this specific RAM does work at 8000 Mhz on MSI Ace MoBo, pcpp: https://uk.pcpartpicker.com/product...dr5-8000-cl40-memory-f5-8000j4048f24gx2-tz5rk

which are the circumstances that 32GB wont be enough?
3D render, CAD designs and the like, where there are loads of data that need to be housed within a RAM while working with a project.

and what kind of cost for the max memory of 192GB? eg what is the low end cost and top end cost for the full 192GB? just to get some perspective of this aspect of the config.
Very limited options. Pcpp doesn't have any 4x 48GB sets and i only found two sets from amazon.uk;
1. Corsair - https://www.amazon.co.uk/Corsair-VENGEANCE-5200MHz-Compatible-Computer/dp/B0BY6ZF5KF
2. Corsair with RGB - https://www.amazon.co.uk/CORSAIR-VENGEANCE-5200MHz-Compatible-Computer/dp/B0BY6Y85PZ

Both are 5200 Mhz, CL38 and 14,61 nanoseconds of response time. Price wise, £650-£675.


Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
The MoBo OP is going for, has AMD multi-GPU support and i've explained to OP what it is and use cases where one would use two GPUs. Namely for workstation use, by spreading the load between two GPUs (helpful in 3D render projects). Due to that, multi-GPU is one option that OP can go for, if they have a need for it.

I'll probably not go for 2 GPUs then,

Do note that you can't use two RTX 4090 GPUs in this system since PSU is way too weak to run two RTX 4090 GPUs. It is enough for one RTX 4090. Going with 2kW PSU should suffice, or when you get 2nd PSU just to power 2nd RTX 4090. Still, with the price of one RTX 4090, not worth to use two in the same system. In workstation usage, Nvidia Quadro would be far better option. Like RTX 6000 Ada Generation,
Nvidia: https://store.nvidia.com/en-us/nvidia-rtx/store/?page=1&limit=9&locale=en-us

If you do like to end up using multiple-GPU setup, i suggest going with Quadro instead. GeForce GPUs are designed for gaming use, while Quadro GPUs are designed for workstation use.

In a nutshell:
GeForce/Radeon - jack of all trades, master of one (gaming).
Quadro/Radeon Pro (FirePro) - jack of all trades, master of all but one (everything else, except gaming).

Further reading and to help you decide between workstation or gamer GPU,
link: https://www.gpumag.com/nvidia-quadro-vs-geforce/

I suggest that you read it. It's nice article. :)


Yes, there are and actually several variants as well;
4060 series = 4060, 4060 Ti 8GB, 4060 Ti 16GB,
4070 series = 4070, 4070 Super, 4070 Ti, 4070 Ti Super
4080 series = 4080, 4080 Super
4090 series = 4090

"Super" cards are actually the latest releases, released a day ago or so.
I'll probably go for the £300 one then, and just get one GPU eventually.

I think there is wisdom in going for the most popular components for some things, as these will be cheaper because of economies of scale, and also it means if I make any software available to others, it will be better tested.

if I got some exclusive hardware, the software might only run properly on some systems.

I remember with the Amiga computer scene, that software houses needed to write software which worked on default machines. if software only ran on top end machines, they wouldnt sell many.


No.

Latest Threadripper CPUs, 7000-series, are using sTR5 CPU socket.
Further reading: https://en.wikipedia.org/wiki/List_..._Peak_(Threadripper_7000_series,_Zen_4_based)

Price is also hefty per CPU;
7960X - $1499 USD
7970X - $2999 USD
7980X - $4999 USD

While Threadripper Pro CPUs are still TBA (To Be Announced).


Different MoBo and CPU cooler is a must. PSU will do fine, since all 7000-series Threadripper and Threadripper Pro CPUs are rated for 350W.
ok, I was checking what the options were if I get the mobo first. as soon as you buy one component, that starts limiting other choices.

although the prices are expensive, that isnt necessarily a deal breaker, because I may use the computer for 10 years, where the $4999 is then some $500 a year, ie some $10 a week, which is maybe $40 a month.

the thing is I am subscribed to some financial charting software which is £59/month, which I dont use much, so if I cancel that, that saving then covers the $40. I am going to cancel that 59 anyway, and not get the 7980X also!

from the info so far, what I would say is $4999 for the CPU isnt a deal breaker, but even $2000 is a deal breaker for the GPU! what is a deal breaker for the threadripper is more the heat.

the other deal breaker is just that I dont think I will need the power of the threadripper. it would be inefficient use of money.

the decisions are a balancing act. I have my main money invested at 9%, so say I spend an extra £5000 on the system, then my annual income drops by £450. Thus any spending at all is to remove that money from something else. money is there to be spent, but in my opinion most money is there to be invested, and just the interest is for spending.

also potentially in a few years I might upgrade again, so an extra £5000 might be better spent in 5 years time, where it would then be 5000 + 5 x 450 = 7250, where the interest would be £2250 "free money"!

where the interest would pay for most of a system. ie if I kept 5000 invested permanently, I could buy a system with the interest say every 5 years!

this is the dilemma of delaying leads to better deals: better technology, lower prices, but whilst you delay you have nothing!

I delayed buying a smartphone till 2015, when I got a Samsung Galaxy Note 4 for some 460 online, and now had the best smartphone on the buses. as the months rolled by, eventually the Apples outdid it!
Far more GPU compute power. Also, higher power consumption and more heat produced as well. Oh, GPU itself (physical size) is also larger, namely due to the cooler it has on it.


Since GeForce GPUs are designed for gaming, you'd get more FPS (Frames Per Second) with RTX 4090 than with RTX 4060. Quite a bit more actually.
Comparison: https://www.topcpu.net/en/gpu-c/NVIDIA-GeForce-RTX-4060-vs-NVIDIA-GeForce-RTX-4090

Tech specs:

GPU nameRTX 4060RTX 4090
Pipelines / CUDA cores307216384
Core clock speed1830 MHz2235 MHz
Boost clock speed2460 MHz2520 MHz
Number of transistors35,800 million76,300 million
Manufacturing process technology5 nm5 nm
Power consumption (TDP)115 Watt450 Watt
Texture fill rate236.21,290
Memory typeGDDR6GDDR6X
Maximum RAM amount8 GB24 GB
Memory bus width128 Bit384 Bit
Memory clock speed17000 MHz21000 MHz
Memory bandwidth272.0 GB/s1,008 GB/s
Shared memory--

Depending on a resolution and game in question, RTX 4090 is anywhere between 80% up to 420% better than RTX 4060.
But this only matters if you play games. If you do not, it matters little in terms of FPS these GeForce GPUs produce. And as i said earlier, if you'd need GPU for 3D render or number cruncing, Quadro is far better choice. One thing that Quadro GPUs have, over gaming (GeForce) GPUs, is that all Quadro GPUs also have ECC VRAM.


It depends on your usage case of a CPU/GPU.
you have convinced me its better to just go for say one of the £300 GPUs, initially I wont get a GPU.

when you say "3D render", are you talking about rendering to display later? eg where they create 3D Hollywood films.

as compared to live 3D images?

will say the RTX 4060 be able to output 3D images to say an active 3D TV via HDMI?

eg I bought a 50" active 3D Panasonic TV, I didnt get a wider screen because that would block the patio exit of the room! I learnt also that bigger tvs are more hassle to move around and install on a stand. major effort to replace the dubious manufacturer stand with a fully tiltable rotatable stand from the internet.

is there much software that outputs 3D images?

eg in one era I found there were some 3D videos on Youtube, but not sure how to view those.

at the moment the only way I can view 3D videos, eg the London 2012 olympics highlights were broadcast in 3D in the UK, is to use my 3D panasonic bluray players, I have a 3D Panasonic bluray writer tv box which I recorded the London 2012 olympics, and a Wimbledon in that era, which the BBC broadcast in 3D. the BBC eventually stopped broadcasting in 3D.

I have a few Hollywood films in 3D, eg the Trolls world tour.

Sure, as a daily driver for groceries shopping, lorry is too much. But if you're in the business of moving stuff, small passenger car just doesn't cut it. Sure, you could hook small trailer behind it but passenger car still doesn't cut it compared to lorry. In this example, cargo van would be best option. But lorry can also be a good option if you look at it as an investment to the future, IF you expect your business to grow, whereby you are going to utilize the lorry at it's fullest.

In similar sense, buying Threadripper CPU or Quadro GPU is same. It's an investment for the future and not an expenditure for entertainment.


Comparison, pcpp: https://uk.pcpartpicker.com/products/compare/HZLdnQ,xK88TW,8wyH99/

Three RAM kits are compared there;
1. the cheapest option i talked about (£220, 6000 Mhz, CL36, response time 12 nanoseconds),
2. the one i included in your build (£255, 6400 Mhz, CL32, response time 10 nanoseconds)
3. and the top end one (£390, 6600 Mhz, CL32, response time 9,697 nanoseconds).

Top end one isn't justified in price increase of £135 while only gaining 200 Mhz faster frequency, which at same CAS Latency, brings the response time from 10 nanoseconds down to 9,697 nanoseconds. Gain of 0,303 nanoseconds isn't worth the €130.
Cheapest option compared to what i included, has 400 Mhz less frequency and 2 nanoseconds longer response time, with a saving of only £35. So, at that price point, going with the one i included to the build, is cost effective.


This, pcpp: https://uk.pcpartpicker.com/products/compare/mHYmP6,xQ8bt6,xK88TW/

Again, three RAM kits are compared there;
1. the one i included in your build (4x 16GB),
2. the one that has the fastest frequency (8000 Mhz) for 2x 16GB
3. and the one that has the shortest response time (9,231 nanoseconds) for 2x 16GB.

Now, the shortest response time 2x 16GB set does have 7800 Mhz frequency, gain of 1200 Mhz over 6400 Mhz kit i included and is 0,769 nanoseconds faster in terms of response time, while costing £48 less. But with this, you'll get only half of RAM amount, 32GB vs the one i included, 64GB.
Fastest frequency RAM, at 8000 Mhz, has gain of 1600 Mhz over the one i included, while also offering 0,5 nanoseconds faster response time. But it will cost £112 more than the one i included, while offering half the RAM capacity. So, not worth the buy.

scrutinising the info, your 4 x 16GB recommendation does look the best.

where that 64GB deal is significantly lower price per GB than the 32GBs, and looks like the best deal for the 64GBs, if I went upwards from 64GB, is there some memory size which is even more optimal?

I imagine the most popular sizes will be the best value for money.

the info you have given suggests that up to 64GB, your recommendation is best, but what about when you go above 64GB?



Of course, RAM speeds faster than ~6600 Mhz always have the issue of not actually being able to run at so high frequency as they are rated for. Sure, RAM manufacturer has successfully tested the RAM to be stable at 7800/8000 Mhz and MoBo manufacturer has also tested that their MoBo can run RAM at 7800/8000 Mhz, but it is only select few RAM kits that can do that.

For example, MSI has tested that only 4 RAM kits are capable of running at 8000 Mhz on their Ace MoBo. Two are 48GB sets and other two are 32GB sets.
MSI Ace MoBo memory QVL: https://www.msi.com/Motherboard/MEG-X670E-ACE/support#mem

E.g this specific RAM does work at 8000 Mhz on MSI Ace MoBo, pcpp: https://uk.pcpartpicker.com/product...dr5-8000-cl40-memory-f5-8000j4048f24gx2-tz5rk
are you talking exclusively about overclocking here?

3D render, CAD designs and the like, where there are loads of data that need to be housed within a RAM while working with a project.
I wont be doing any CAD!

if the day came where I had to do something specialised like that, I'd buy a system around that requirement, and probably as an investment for the work, the same way a salesman might buy a car for doing his salesmanship, where the hope is the money you make from using the equipment pays for the equipment, ie the equipment pays for itself, and where probably one could get some kind of tax discounts.



Very limited options. Pcpp doesn't have any 4x 48GB sets and i only found two sets from amazon.uk;
1. Corsair - https://www.amazon.co.uk/Corsair-VENGEANCE-5200MHz-Compatible-Computer/dp/B0BY6ZF5KF
2. Corsair with RGB - https://www.amazon.co.uk/CORSAIR-VENGEANCE-5200MHz-Compatible-Computer/dp/B0BY6Y85PZ

Both are 5200 Mhz, CL38 and 14,61 nanoseconds of response time. Price wise, £650-£675.
that looks like an extra £400 versus the 4x16GB recommendation.

the price ratio is 650/256 = 2.54x, and the capacity ratio is 192/64 = 3, so it is arguably 18% better value for money. not a ginormous boost in value.


5200MHz is slower than the 6400MHz of your recommendation, but this 5200MHz is faster?

sounds paradoxical! slower frequency yet faster, have I misunderstood something?


the current decision remains at that full config you gave, but some discussion to scrutinise the decision, whether to modify the decision in any way. eg with the memory whether going for more or going for less could be a better decision, you have convinced me going for less is probably a bad decision.

for going above 64GB = 4 x 16GB, are the only options 4 x 32GB and 4 x 48GB?

computer hardware generally works with powers of 2, 48 isnt a power of 2, I just have to wonder if 4 x 32GB could be more favourable than 4 x 48GB?

I find it unusual that the limit is 4 x 48GB, rather than 4 x 32GB or 4 x 64GB, why this unusual limit?

eg with SCSI, you have I think 8 devices, where 1 of them is the SCSI adapter, ie 7 external devices.

I find the 192GB anomalous, for not being a power of 2.



with GPUs going for dual GPU or top end GPU also seems a bad decision for my circumstance.

I dont play video games anymore, because too addictive!

when I have played video games, I generally prefer 2D games, eg I liked "cradle of Rome", and this kind of game doesnt need a GPU. in the 1988 era there was a really great version of Boulderdash for the Amiga, where the people had run into copyright problems and the programmers released it for free in the underground. Lemmings and Tetris were also great 2D games. in that era, the arcades had real time 3D graphics, eg things like car racing and skiing, no idea what computers they used, but the graphics were impressive.

that Boulderdash didnt have any music, but it had really interesting sound effects for each graphical phenomenon which was better than music. it had maybe 100 screens, where each screen was a kind of puzzle, where you had to get to the exit door, but you had to use elusive tricks to get there.

I dont use CAD either, never have and probably never will.

so to some extent a GPU is wasted on me!

but I may want to get one just to experiment programming, but just as a hobby and out of curiosity. I dont want to get into commercial programming.

  • Like
Reactions: 35below0

Aeacus

Titan
Ambassador
when you say "3D render", are you talking about rendering to display later? eg where they create 3D Hollywood films.

as compared to live 3D images?
3D rendering is the process of creating a photorealistic 2D image from 3D models. 3D rendering is the final step in the process of 3D visualisation, which involves creating models of objects, texturing those objects and adding lighting to the scene.

will say the RTX 4060 be able to output 3D images to say an active 3D TV via HDMI?
Depends on the TV resolution and refresh rate. The higher the resolution and refresh rate - the harder the GPU has to work. TV diagonal size doesn't matter here at all.

3D imagery doesn't put any additional load on a GPU than standard 2D imagery. Just to create the 3D effect, either it uses red/greenish color distortion or side-by-side imagery which effect is then completed with special 3D glasses.

So, your TV resolution and refresh rate is?

if I went upwards from 64GB, is there some memory size which is even more optimal?
Depends what metric you want to use, for optimal RAM. Is it:
* price per GB
* fastest frequency
* shortest response time
* highest capacity
?

If it is price per GB, then this 2x 32GB kit,
pcpp: https://uk.pcpartpicker.com/product...2-gb-ddr5-4800-cl40-memory-cmk64gx5m2a4800c40
is value king. It's price is £2.278 per GB.
£145.82 for entire kit.

But just because it is value king, doesn't mean the RAM itself is most optimal. For one, it's CAS Latency is 40, making it's response time 16,667 nanoseconds, which for DDR5, is quite high. Also, it is running stock 4800 Mhz frequency, slowest of all DDR5.

are you talking exclusively about overclocking here?
Yes and this is by built-in OC profile, known as EXPO for AMD (XMP for Intel).

4800 Mhz is the JEDEC default. Anything higher than that, requires you to enable RAM EXPO profile.

MSI Ace supported RAM speeds: Memory Support DDR5 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz.

5200MHz is slower than the 6400MHz of your recommendation, but this 5200MHz is faster?

sounds paradoxical! slower frequency yet faster, have I misunderstood something?
I think you misunderstood the response time in nanoseconds i talked about.

The less response time there is (in nanoseconds), the faster the RAM is.
So, 4x 48GB set is 5200 Mhz but since it's CAS Latency is 38, it's actual response time is 14,61 nanoseconds.
4x 16GB i included to the build is 6400 Mhz with CAS Latency of 32, with response time of 10 nanoseconds.

for going above 64GB = 4 x 16GB, are the only options 4 x 32GB and 4 x 48GB?
Besides 4x 16GB (64GB), there is also 4x 24GB (96GB), 4x 32GB (128GB) and 4x 48GB (192GB).

I find it unusual that the limit is 4 x 48GB, rather than 4 x 32GB or 4 x 64GB, why this unusual limit?
Well, CPU supports up to 128GB of RAM, while chipset supports up to 192GB of RAM.

And since consumer MoBos can have up to 4x RAM slots, max memory is combination of 4x RAM sticks. Not all capacity single sticks are available for DDR5.

1x 4GB - DDR2, DDR3, DDR4
1x 8GB - DDR2, DDR3, DDR4, DDR5
1x 16GB - DDR3, DDR4, DDR5
1x 24GB - DDR5
1x 32GB - DDR3, DDR4, DDR5
1x 48GB - DDR5
1x 64GB - DDR4
1x 128GB - DDR4

So, with DDR5, combination is between 8GB, 16GB, 24GB, 32GB or 48GB RAM sticks. While 24GB and 48GB sticks are exclusive for DDR5.

Since there are no 1x 64GB DDR5 sticks, MoBos can't have their max RAM support as 4x 64GB DDR5.
Highest capacity stick for DDR5 is 48GB, thus, max what consumer MoBo with 4x RAM slots can offer, is 4x 48GB = 192GB DDR5.

Maybe in the future, there could be 1x 64GB and 1x 128GB DDR5 sticks, but as of right now, single most dense RAM stick for DDR5 is 48GB.

I find the 192GB anomalous, for not being a power of 2.
If you look the capacity of single RAM sticks, you'll see that RAM actually uses power of 8 (or 4), rather than power of 2.

so to some extent a GPU is wasted on me!
In this case, ~£300 RTX 4060 would do. If you ever find that RTX 4060 is too weak for your use case, you can always replace the GPU with beefier one. Be it RTX 4070, RTX 4080 and their variants, or even up to RTX 4090.

Last edited:

Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
3D rendering is the process of creating a photorealistic 2D image from 3D models. 3D rendering is the final step in the process of 3D visualisation, which involves creating models of objects, texturing those objects and adding lighting to the scene.


Depends on the TV resolution and refresh rate. The higher the resolution and refresh rate - the harder the GPU has to work. TV diagonal size doesn't matter here at all.

3D imagery doesn't put any additional load on a GPU than standard 2D imagery. Just to create the 3D effect, either it uses red/greenish color distortion or side-by-side imagery which effect is then completed with special 3D glasses.

So, your TV resolution and refresh rate is?

4K Ultra HD, 50Hz and 60Hz

https://www.panasonic.com/uk/support/discontinued-products/televisions/tx-50dx802b.specs.html

the important fact about this tv is it is active 3D but that info is well hidden in the specification!

without active 3D it is just another wide screen tv.

I think around 2012, there were tons of 3D tvs for sale, but by 2018, I think just 2 panasonics, decided to get one before they vanished. have only watched a few things in 3D and its really great, eg trolls world tour, that has some really zany 3D cartoons with lurid colours in 3D space.

just the box of that TV was a nightmare, ginormous, the specs say the boxed weight is 32kg. John Lewis has some really ginormous TVs, could even be 100", must be near impossible to install those!

I think a 3D projector might be a better option. there's an audiovisual shop in town, where they have a mini cinema to demonstrate their products. I wanted a player that could handle my 3D recordings of the 2012 London Olympics, I had bought an LG or Sony or Samsung which couldnt handle the 3D recordings, and they tested the disk in the mini cinema to verify the disk was alright, and it was sublime seeing the recordings on a big screen.

I want to get a 3D camcorder also eventually, that way to not just film a holiday, but to film in 3D!

Panasonic have really advanced technology called 3MOS, where they have a MOS for each of red, green, blue, whereas most camcorders just have 1 MOS for all 3 colours. When I tested out a 2D Panasonic 3MOS camcorder at the Panasonic store in 2012, they replayed it on an HD tv, and it was higher quality than the HD television station's broadcast!

Depends what metric you want to use, for optimal RAM. Is it:
* price per GB
* fastest frequency
* shortest response time
* highest capacity
?

If it is price per GB, then this 2x 32GB kit,
pcpp: https://uk.pcpartpicker.com/product...2-gb-ddr5-4800-cl40-memory-cmk64gx5m2a4800c40
is value king. It's price is £2.278 per GB.
£145.82 for entire kit.

But just because it is value king, doesn't mean the RAM itself is most optimal. For one, it's CAS Latency is 40, making it's response time 16,667 nanoseconds, which for DDR5, is quite high. Also, it is running stock 4800 Mhz frequency, slowest of all DDR5.
the 16.667 is too slow, based on the other memory, I'd say approx 10ns or less. not worried about say 10%, eg 11ns would be alright.


Yes and this is by built-in OC profile, known as EXPO for AMD (XMP for Intel).

4800 Mhz is the JEDEC default. Anything higher than that, requires you to enable RAM EXPO profile.

MSI Ace supported RAM speeds: Memory Support DDR5 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz.


I think you misunderstood the response time in nanoseconds i talked about.

The less response time there is (in nanoseconds), the faster the RAM is.
So, 4x 48GB set is 5200 Mhz but since it's CAS Latency is 38, it's actual response time is 14,61 nanoseconds.
4x 16GB i included to the build is 6400 Mhz with CAS Latency of 32, with response time of 10 nanoseconds.

ok, I got confused, for some reason I thought 14.61 ns was better than 10ns! I think because the 2 numbers werent in the same bit of webpage and it was late at night, I probably got my wires crossed with other numbers.

I think 4 x 48GB is then ruled out because too slow.

what exactly is CAS latency?


Besides 4x 16GB (64GB), there is also 4x 24GB (96GB), 4x 32GB (128GB) and 4x 48GB (192GB).


Well, CPU supports up to 128GB of RAM, while chipset supports up to 192GB of RAM.

And since consumer MoBos can have up to 4x RAM slots, max memory is combination of 4x RAM sticks. Not all capacity single sticks are available for DDR5.

1x 4GB - DDR2, DDR3, DDR4
1x 8GB - DDR2, DDR3, DDR4, DDR5
1x 16GB - DDR3, DDR4, DDR5
1x 24GB - DDR5
1x 32GB - DDR3, DDR4, DDR5
1x 48GB - DDR5
1x 64GB - DDR4
1x 128GB - DDR4

So, with DDR5, combination is between 8GB, 16GB, 24GB, 32GB or 48GB RAM sticks. While 24GB and 48GB sticks are exclusive for DDR5.

Since there are no 1x 64GB DDR5 sticks, MoBos can't have their max RAM support as 4x 64GB DDR5.
Highest capacity stick for DDR5 is 48GB, thus, max what consumer MoBo with 4x RAM slots can offer, is 4x 48GB = 192GB DDR5.

Maybe in the future, there could be 1x 64GB and 1x 128GB DDR5 sticks, but as of right now, single most dense RAM stick for DDR5 is 48GB.
ok its complicated!

which is the max memory size stick that is approx 10ns or less?

in order to get the max memory size of 10ns or less,

the 16GB (x4) you recommended can do 10ns, but is there a 24GB or 32GB that can also? and then the best value for GB/price?

I wont necessarily go for such if it exists, but to understand the options.

with multiple sticks to get maximum speed should the sticks always be identical?

you said that some options dont need to be a factory sealed batch of identical ones,

ie are the potential options above 4 x 16GB for 10ns or less, 4 x 24GB and 4 x 32GB?

I might go for a higher size if its good value for money, just to keep my options open.

Bill Gates once said nobody can need more than 640K!

the internet says he denies saying that, but maybe he said it in some context eg for some specific problem or that no home user needed more than 640K at that time, or he forgot he said it.


If you look the capacity of single RAM sticks, you'll see that RAM actually uses power of 8 (or 4), rather than power of 2.
power of 8 is a power of 2! because 8 is a power of 2, eg
8^3 = 8 x 8 x 8 = (2 x 2 x 2) x (2 x 2 x 2) x (2 x 2 x2)=2^9

similarly with powers of 4, eg 4^3 = 4 x 4 x 4 = (2 x 2) x (2 x 2) x (2 x 2) = 2^6

more generally powers of powers of a are powers of a, a^(bxc) = (a^b)^c

put a = 2, b =3 and you get 2^(3 * c) = 8^c

In this case, ~£300 RTX 4060 would do. If you ever find that RTX 4060 is too weak for your use case, you can always replace the GPU with beefier one. Be it RTX 4070, RTX 4080 and their variants, or even up to RTX 4090.
I'll start without a GPU, and then eventually maybe get one RTX 4060, with time the prices will probably come down, where the 4090 might become much more affordable.

without GPU, will the computer handle HD and higher resolutions?


Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
Right. That is not unusual.

But often, the upgrade path ends up worse than a clean install.
Not always, but it does happen.

you should try a clean install first, but if that fails you may have to try some tricks.

if you are going to upgrade or even repair an install, I would seriously advise to make a sector by sector backup of the drive FIRST, just in case the upgrade or repair fails. I have had XP repairs fail, and am then neither here nor there.

Linux is great for doing sector by sector backups of Windows system drives, because you avoid the risk of the drive being modified whilst being copied which would lead to an incoherent image. where what I do is boot Linux from an optical disk, with "try without installing", which is often a better environment than installing! as the "try without installing" CAN have some really useful programs pre-installed.

the Linux command I use is something like:

sudo dd if=/dev/sdb | gzip -c >> some_huge_file.gz

where "|" is the midbar symbol, used for Unix "pipes" where the output of one command is the input of the next, stdout and stdin of C programs.

and where /dev/sdb is a path dependent on the version of Linux and the specific disk config, you have to run a partition editor to find the specific path to use,

that command will both be sector by sector and compressed.

but you could also clone directly to another drive with something like:

sudo dd if=/dev/sdb of=/dev/sdc

what is great about Linux is you can treat the entire hard disk as if its a file, where the dd command copies files, but will accept the underlying sectors of a drive as if they are a file.

for a file on the filing systems, the paths for Ubuntu are something like eg
/media/volume_name/directory1/directory2/file.jpg


the following Linux command lists out the volumes, I forget if it gives the appropriate paths:

df -h

Linux Mint uses a totally different naming scheme from say Linux Ubuntu.

not tried this on Mint, but with Ubuntu, because disk copying can take hours, you can do a progress indicator thus:

sudo dd if=/dev/sdc of=/dev/sdb & pid=$!

then from the same shell:

sudo kill -USR1 $pid

will give progress info.

no idea what is going on just that it works!
to halt the copying, from the same shell:

sudo kill -ABRT $pid

where the following gives info on the kill command:
help kill
or possibly
sudo help kill


Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
Yes and this is by built-in OC profile, known as EXPO for AMD (XMP for Intel).

4800 Mhz is the JEDEC default. Anything higher than that, requires you to enable RAM EXPO profile.

MSI Ace supported RAM speeds: Memory Support DDR5 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz.


I think you misunderstood the response time in nanoseconds i talked about.

The less response time there is (in nanoseconds), the faster the RAM is.
So, 4x 48GB set is 5200 Mhz but since it's CAS Latency is 38, it's actual response time is 14,61 nanoseconds.
4x 16GB i included to the build is 6400 Mhz with CAS Latency of 32, with response time of 10 nanoseconds.
could you clarify also that the 6400MHz 10ns of the memory you recommended, that this isnt overclocked?

but I have to set something in the mobo UEFI settings because it is above the 4800 MHz?


Aeacus

Titan
Ambassador
4K Ultra HD, 50Hz and 60Hz
This equals to 3840x2160 and either 50 FPS or 60 FPS.

If it were for gaming, where GPU has to compute the graphics, RTX 4060 is too weak to push 50-60 FPS at 4K. Best it could do, is ~32FPS.
But since video file is already computed graphics and GPU only has to deliver it to TV, RTX 4060 does just fine + then some.

Even my old (and now retired) GTX 1060 3GB can play 4K videos at 60 FPS. Heck, mine can even play up to 8K videos (same is with every modern GPU currently out there).

what exactly is CAS latency?
CAS = Column Access Strobe. Time it takes RAM to start accessing data in the RAM, measured in clock cycles.

Nice short video explaining it:
(CAS Latency is at 1:05 or watch entire 5min video)

View: https://www.youtube.com/watch?v=Yed-a9vqTYc


which is the max memory size stick that is approx 10ns or less?
48GB stick. Namely 2x 48GB kit.

the 16GB (x4) you recommended can do 10ns, but is there a 24GB or 32GB that can also? and then the best value for GB/price?
2x 48GB (96GB), 6600 Mhz, CL32, 9.697ns, £331.05, £3.448 per GB, pcpp: https://uk.pcpartpicker.com/product...8-gb-ddr5-6600-cl32-memory-cmh96gx5m2b6600c32
4x 24GB (96GB), 6000 Mhz, CL30, 10ns, £379.99, £3.958 per GB, pcpp: https://uk.pcpartpicker.com/product...4-gb-ddr5-6000-cl30-memory-cmk96gx5m4b6000c30
4x 32GB (128GB) kits have response time 14.286ns or higher and no point to list those.

Note: The 4x 16GB kit i included in your build has £4.008 per GB value.

with multiple sticks to get maximum speed should the sticks always be identical?
Yes, if you want the RAM to actually work at advertised speeds. Now, mixing memory is longer talk and here i strongly suggest that you read this article,
link: https://forums.tomshardware.com/faq...y-ram-and-xmp-profile-configurations.3398926/

Especially "mixed memory" chapter (2nd chapter), to understand why always, whenever possible, to buy RAM kits, rather than individual sticks and/or mixing kits.

you said that some options dont need to be a factory sealed batch of identical ones,

ie are the potential options above 4 x 16GB for 10ns or less, 4 x 24GB and 4 x 32GB?
Above i linked the 2x 48GB kit that has 9.697ns and £3.448 per GB. Now, using these two sticks will bring your RAM amount to 96GB, half of maximum support. If you were to buy 2nd set and include all 4x RAM sticks in your build, to get 192GB in total, do note that there is a risk of all 4 sticks not working together since you combined two individual kits.
Likelihood that two kits working together is actually unknown, but for safe measure, i'd put it 50:50 chance.

As of what can happen, when combining two separate kits;
* PC can't detect any RAM and PC won't work
* PC can't detect two modules, leaving only two RAM sticks operational (96GB)
* PC can detect all modules but is only able to run the RAM at JEDEC speed of 4800 Mhz with CL40, 16.66ns, 1.1V
* PC can detect all modules and is able to run the RAM at advertised speeds of 6600 Mhz with CL32, 9.697ns, 1.4V

So, to ensure that you can run the RAM at advertised speeds and it actually working together, better not to combine kits. Unless you want to play RAM lottery and take that risk.

Somewhere in this topic, i explained that i did play this RAM lottery and took that risk, since back in 2016, i didn't have enough money to buy 4x 4GB kit off the bat. I only had money for 2x 4GB kit. So, i did my level best to ensure that when i bought 2nd kit at later date, all 4x sticks would work together. Meaning that i looked my MoBo memory QVL list and bought the very specific RAM that MSI had tested to work at all 4x slots at 3000 Mhz speeds.
Once i had money for 2nd 2x 4GB kit and bought it, i crossed my fingers that: 1. PC is able to detect all 4x sticks; 2. I can enable XMP and run all 4x sticks at 3000 Mhz. I got lucky with this, since my PC did detect all 4x sticks and XMP also worked, whereby i could run my RAM at 3000 Mhz. Now, if the XMP would've not worked, i would've been stuck at 2133 Mhz.

Long story short: Just because i got lucky in RAM lottery, doesn't mean that i suggest it to anyone. On the contrary, i advise against playing RAM lottery since while there have been success cases (like mine), there are also a lot of people who failed and can't get their RAM working at advertised speeds, if PC even works at all, that is.

could you clarify also that the 6400MHz 10ns of the memory you recommended, that this isnt overclocked?
Yes, it is. Like i said earlier, for DDR5, anything above 4800 Mhz is overclock.

Now, you can run that 4x 16GB 6400 Mhz RAM at 4800 Mhz just fine, but RAM will be slower. At 4800 Mhz, CAS Latency will be 40 and response time will be 16.66ns.
So, if you want 10ns or less response time, you have to use overclock, by enabling the built-in RAM overclock EXPO/XMP profile.

Now, if you do not want to use RAM overclock (EXPO/XMP) then the fastest 4800 Mhz RAM with highest capacity (2x 32GB) has CL38 and response time 15.833ns,
pcpp: https://uk.pcpartpicker.com/product...-32-gb-ddr5-4800-cl38-memory-kf548c38bbak2-64

but I have to set something in the mobo UEFI settings because it is above the 4800 MHz?
MoBo should automatically enable the RAM overclock profile. If it does not (or just to check it to be safe), just enter the BIOS and look if RAM runs at advertised speeds or at 4800 Mhz. If it's at 4800 Mhz, then just enable the overclock profile. You do not need to manually adjust RAM voltage and timings, these are included in the RAM overclock profile.

without GPU, will the computer handle HD and higher resolutions?
Yes.

CPU can handle up to 8K (7680x4320) with 60FPS.

But the USB type-C DisplayPort 1.4 with HBR3 on MoBo can't go that high.
What MoBo port can handle at 8K is 31 FPS at color depth of 8bpc. But MoBo port can do 97FPS at 4K at color depth of 10bpc or 120FPS when color depth is 8bpc. So, more than enough for your 4K 50/60Hz TV.

Note: you need to buy USB type-C to DP cable that supports 4K/60FPS if you want to connect monitor/TV to the PC. Since MSI Ace MoBo doesn't have DP/HDMI output port. MoBo only has one USB type-C that supports DisplayPort 1.4 output.

  • Like
Reactions: 35below0

Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
This equals to 3840x2160 and either 50 FPS or 60 FPS.

If it were for gaming, where GPU has to compute the graphics, RTX 4060 is too weak to push 50-60 FPS at 4K. Best it could do, is ~32FPS.
But since video file is already computed graphics and GPU only has to deliver it to TV, RTX 4060 does just fine + then some.

Even my old (and now retired) GTX 1060 3GB can play 4K videos at 60 FPS. Heck, mine can even play up to 8K videos (same is with every modern GPU currently out there).
I am going to take a strategic approach here, as the 4090 is £2200 versus 4060 at £300, that 2200 is a deal breaker, as it will almost double the price of the system. BUT right now, I wont buy a GPU, and maybe as the months go by, the 4090 price will drop, where when I decide to get a GPU the price maybe wont be a deal breaker. maybe some other GPUs emerge also.

will the original configuration you gave be sufficient cooling for the 4090?

as regards FPS, I heard somewhere the human eye handles maybe 30fps, what is the current view say from gamers who are focussed on fps, on what is the max fps a person can handle?

the eye is based on rods and cones, with cones for colour and rods for monochrome, the centre of the eye is 100% cones, and the rods increase as you move outwards. the cones handle slower fps, the rods higher. this is why a light source can be flickering when you look at it with peripheral vision, but when you look directly isnt flickering. Also at night, less bright stars can only be seen sharply if you look slightly away, eg a few degrees, where its not at the centre but slighly off centre.

anyway the peripheral vision will handle a higher fps, eg will notice flicker if the light is oscillating, whereas the central vision handles a lower fps and is less sensitive. where a light source will flicker with peripheral vision but be steady with central vision. if you eat purple vegetables, eg purple cabbage, or "red" grapes, night vision improves, where you can discern colour at night in the darkness.

I have full 180 degree colour, where I can discern colour right to the edge of my peripheral vision, but there must be more cones there as I can discern oscillation and dimmer lights as the light source moves to peripheral vision. the peripheral vision is less precise, where it is just vague shapes.

some people have the retina + lens geometry different, where they have tunnel vision, where they have really high resolution vision, but covering less area. there is major variance of visual performance from person to person. I have met people who can read really small fine text, that I cannot read at all, where they have much higher res vision, that will be where the retina + lens geometry is different. with one such person, we compared what we could see and I had bigger field of view. its like his vision was telephoto, and mine was wide angle!

I think cats have tunnel vision, they dont notice if you are in their peripheral vision. herbivores generally have almost 360 degree vision with their eyes set on the sides of the head. cats eyes are set at the front of the head like with humans.

some women can see 4 primary colours, men cannot see 4 primary colours, this phenomenon relates to a gene on the X chromosome which isnt on the Y chromosome.

anyway, there are no absolute facts about visual performance, the germans did research on perception of colour, eg synonyms, where eg yellow looks the same as red + green. its actually not the same, but its a trick of the mind. red + green + blue is just a sampling of the visual spectrum, and red + green is an interpolation of yellow, the rainbow is red-orange-yellow-green-blue-indigo-violet, where yellow is between red and green, and thus the eye perceives it as red + green, but red + green is the sum of 2 sine waves, a complex wave, whereas true yellow is a sine wave. Sharp created in one era TVs which had red + green + blue + yellow pixel components. humans can only see 3 colours, the wide gamut of colours we perceive are an interpolation of the 3, based on frequency of the nerve signals of each of the 3 colours: the colours are binary, either on or off, but the frequency can be anything. its like max red is 11111111111111.... and very low red will be 100000000000000010000000000000001000000000000000... where the 1's are signal pulses from a red cone. now hearing is totally different, where there is a "hair" for each frequency, with a huge amount of frequencies. basically human hearing is spectral or pseudo-spectral, whereas human hearing is pseudo-digital.

human hearing is on a different level from digital sound. this is where analogue sound eg magnetic tape and vinyl is much nicer as it doesnt have a frequency bias. digital sound is based on sampling at multiples of some frequency quantum, which leads to a bias and causes eg CDs to sound too clear and sparse and causes fatigue of the hairs in the ear (cochlea). I have a midrange hifi system from 1985, and the sound is sublime.

I can listen to that for hours without fatigue, but if I listen to CDs after an hour my ears are fatigued and its not pleasant to continue listening.

one could have say 10 primary colours or 2 primary colours. eg at our uni in 1984 they had a red + green TV projector, based on 2 primary colours, where you had colour but it looked bland. that german research from approx a century ago is the basis of the ICC colour profiles.

where they standardised colour perception via coordinates based on the average perception of their testing, which enables colour input and output to be corrected to look the same on all devices, eg I think sRGB is the main standard. apart from identical inks + identical paper, or identical models, no 2 devices produce the same colour. each has a different "gamut".

even your left eye and right eye perceive colour a bit differently.

with video games, the smaller the screen or the further you stand, the lower the fps you need. if you played a game on a wall to wall screen via a projector, then you might need a higher fps. if the pixels are continual light, not flickering, then lower fps might be alright.


CAS = Column Access Strobe. Time it takes RAM to start accessing data in the RAM, measured in clock cycles.

Nice short video explaining it:
(CAS Latency is at 1:05 or watch entire 5min video)

View: https://www.youtube.com/watch?v=Yed-a9vqTYc
ok, I watched the full video, its interesting. I think the engineers will be guided by the nanosecond delays, where they then arrange the smallest number of clock cycles that covers the nanoseconds!

its like say someone gave you some work to do, and said it would need to be submitted on midday any day, which day can you complete by? and you calculate you could complete it by 3pm Thursday, you'd say you can do the work by midday Friday.

at each part of some circuitry, they need to allow time for say a voltage 1 to become 0 unambiguously,

it might change thus: 1.0, 0.9, 0.8, 0.7, 0.6, 0.5, 0.4, 0.3, 0.2, 0.1, 0.0

where 1.0 to 0.7 will be regarded as 1.0,
0.3 to 0.0 will be regarded as 0.0

0.6 to 0.4 is ambiguous,

they might decide 0.2 is the defining amount, they want all outputs to stabilise unambiguously, which will include all internal voltages.

the max clock speed is the one which allows the entire circuit to be unambiguous.

when I say 1.0 and 0.0, that in fact could be +5.0 and -5.0 or other such numbers. when you change the inputs to a circuit, that change has to progress through all the circuits, like some guys entering a building running to all the offices of the team leaders, telling them to go to the offices of their team members to assemble in the coffee room. you have to allow some time before the coffee room has stabilised with all the people.


modern computers are based on clocks, where each clock cycle is enough time for all voltages to stabilise unambiguously. memory may need several clock cycles, they probably need a counter to delay accessing the memory read to give the memory voltages enough time to stabilise. or the memory could have its own clock and set an acknowledge pin when the memory reading is ready.

if you overclocked too fast, you start to move to the ambiguous zones, where a 1 is misread as a 0 because you havent given the wire enough time to reach the 1 zone. if you are in the outer ambiguous zone, a misreading might just occur once every 10 minutes. move further out and now only once every 30 minutes, eventually you reach the safe zone!

if you have a CPU with addition instruction, the clock cycles for that instruction are usually fixed, and will be the number of clock cycles for the most complicated instruction, this is where you have the most carries, eg

11111111111....1111 + 1,

where the carry has to progress leftwards! 1 + 1 = 0 carry 1, add the 1 to the next 1, you get 0 carry 1, add the carry to the next 1, you get 0 carry 1, etc!

for our exams, we had to be able to draw out the schematic circuitry for adding multiple digits, its not especially difficult.

you literally have to wait for the carries to propagate through the circuits which add each digit, these will have 3 inputs: 1 from each number, and 1 from the carry, and 2 outputs: the output digit and the carry, which is then fed into the next binary digit adder.



64 bit addition will have twice as slow slowest instruction as 32 bit addition!

with the original ARM cpu for the Acorn Archimedes computer, they got rid of the multiplication instruction in order to make the CPU faster. you had to do multiplication in software.

ARM = "Acorn Risc Machine".

people will have clever ways of doing multiplication in software, they probably wont do it the way you learnt at school.




48GB stick. Namely 2x 48GB kit.


2x 48GB (96GB), 6600 Mhz, CL32, 9.697ns, £331.05, £3.448 per GB, pcpp: https://uk.pcpartpicker.com/product...8-gb-ddr5-6600-cl32-memory-cmh96gx5m2b6600c32

I think I will go for this one, its just 74.56 more expensive, which is 2.76% extra price for the system.

https://uk.pcpartpicker.com/product...8-gb-ddr5-6600-cl32-memory-cmh96gx5m2b6600c32
4x 24GB (96GB), 6000 Mhz, CL30, 10ns, £379.99, £3.958 per GB, pcpp: https://uk.pcpartpicker.com/product...4-gb-ddr5-6000-cl30-memory-cmk96gx5m4b6000c30
4x 32GB (128GB) kits have response time 14.286ns or higher and no point to list those.

Note: The 4x 16GB kit i included in your build has £4.008 per GB value.


Yes, if you want the RAM to actually work at advertised speeds. Now, mixing memory is longer talk and here i strongly suggest that you read this article,
link: https://forums.tomshardware.com/faq...y-ram-and-xmp-profile-configurations.3398926/

Especially "mixed memory" chapter (2nd chapter), to understand why always, whenever possible, to buy RAM kits, rather than individual sticks and/or mixing kits.

ok, I just read that 2nd chapter, as I would need the mobo to make sense of the 1st chapter.

if I get the above 2 x 48GB, I wont use the other 2 sockets.



Above i linked the 2x 48GB kit that has 9.697ns and £3.448 per GB. Now, using these two sticks will bring your RAM amount to 96GB, half of maximum support. If you were to buy 2nd set and include all 4x RAM sticks in your build, to get 192GB in total, do note that there is a risk of all 4 sticks not working together since you combined two individual kits.
Likelihood that two kits working together is actually unknown, but for safe measure, i'd put it 50:50 chance.
I wont take the risk!

if I were to upgrade the memory in the future, I'd remove the existing ones and buy a full new set fresh.

with time, prices drop, so buying a full new set say in 2 years time, could be cheaper than buying the remaining set now.

As of what can happen, when combining two separate kits;
* PC can't detect any RAM and PC won't work
* PC can't detect two modules, leaving only two RAM sticks operational (96GB)
* PC can detect all modules but is only able to run the RAM at JEDEC speed of 4800 Mhz with CL40, 16.66ns, 1.1V
* PC can detect all modules and is able to run the RAM at advertised speeds of 6600 Mhz with CL32, 9.697ns, 1.4V

So, to ensure that you can run the RAM at advertised speeds and it actually working together, better not to combine kits. Unless you want to play RAM lottery and take that risk.

Somewhere in this topic, i explained that i did play this RAM lottery and took that risk, since back in 2016, i didn't have enough money to buy 4x 4GB kit off the bat. I only had money for 2x 4GB kit. So, i did my level best to ensure that when i bought 2nd kit at later date, all 4x sticks would work together. Meaning that i looked my MoBo memory QVL list and bought the very specific RAM that MSI had tested to work at all 4x slots at 3000 Mhz speeds.
Once i had money for 2nd 2x 4GB kit and bought it, i crossed my fingers that: 1. PC is able to detect all 4x sticks; 2. I can enable XMP and run all 4x sticks at 3000 Mhz. I got lucky with this, since my PC did detect all 4x sticks and XMP also worked, whereby i could run my RAM at 3000 Mhz. Now, if the XMP would've not worked, i would've been stuck at 2133 Mhz.

Long story short: Just because i got lucky in RAM lottery, doesn't mean that i suggest it to anyone. On the contrary, i advise against playing RAM lottery since while there have been success cases (like mine), there are also a lot of people who failed and can't get their RAM working at advertised speeds, if PC even works at all, that is.
my MO is to really think hard at the outset, and then stick to that decision. best to overestimate, but not if the price goes up majorly. for the scenario of memory, I would discard the original set and buy a fresh lot with more memory.

with many things in life, you are stuck with your decisions, eg car and house and specialism etc,

there is a saying "act in haste, repent at leisure"

if I go for 96GB, I reduce the risk of needing to increase the memory, and I push further into the future such a decision, where hopefully the price for a fresh new set will be much cheaper!


Yes, it is. Like i said earlier, for DDR5, anything above 4800 Mhz is overclock.

Now, you can run that 4x 16GB 6400 Mhz RAM at 4800 Mhz just fine, but RAM will be slower. At 4800 Mhz, CAS Latency will be 40 and response time will be 16.66ns.
So, if you want 10ns or less response time, you have to use overclock, by enabling the built-in RAM overclock EXPO/XMP profile.

but are there 2 forms of overclocking?

safe overclocking, approved by the manufacturers of the mobo, cpu and memory module, where all guarantees are satisfied,

and unsafe overclocking, which you do at your own risk?


Now, if you do not want to use RAM overclock (EXPO/XMP) then the fastest 4800 Mhz RAM with highest capacity (2x 32GB) has CL38 and response time 15.833ns,
pcpp: https://uk.pcpartpicker.com/product...-32-gb-ddr5-4800-cl38-memory-kf548c38bbak2-64


MoBo should automatically enable the RAM overclock profile. If it does not (or just to check it to be safe), just enter the BIOS and look if RAM runs at advertised speeds or at 4800 Mhz. If it's at 4800 Mhz, then just enable the overclock profile. You do not need to manually adjust RAM voltage and timings, these are included in the RAM overclock profile.


Yes.

CPU can handle up to 8K (7680x4320) with 60FPS.

But the USB type-C DisplayPort 1.4 with HBR3 on MoBo can't go that high.
What MoBo port can handle at 8K is 31 FPS at color depth of 8bpc. But MoBo port can do 97FPS at 4K at color depth of 10bpc or 120FPS when color depth is 8bpc. So, more than enough for your 4K 50/60Hz TV.

Note: you need to buy USB type-C to DP cable that supports 4K/60FPS if you want to connect monitor/TV to the PC. Since MSI Ace MoBo doesn't have DP/HDMI output port. MoBo only has one USB type-C that supports DisplayPort 1.4 output.

does the mobo support HDMI to use initially?

that TV is for later in the future, initially I would use the monitor here, I have to research that later as running out of time now

the TV would just be for things like impressive 3D, not for everyday use.


Aeacus

Titan
Ambassador
and maybe as the months go by, the 4090 price will drop, where when I decide to get a GPU the price maybe wont be a deal breaker. maybe some other GPUs emerge also.
GPU prices rarely drop below MSRP. On the contrary, when new GPUs are launched, their price often rises over MSRP due to high demand.

As of new GPUs to come, we are expecting Nvidia RTX 50-series around end of 2024, beginning of 2025.

will the original configuration you gave be sufficient cooling for the 4090?
All GPUs come with their own dedicated cooler that is designed to cool the GPU if no additional airflow is present. But additional airflow helps. Also, build i suggested does fine in terms of cooling, given that you go with Noctua fans and install all of them.

as regards FPS, I heard somewhere the human eye handles maybe 30fps, what is the current view say from gamers who are focussed on fps, on what is the max fps a person can handle?
Most people have their vision between 30 and 60FPS. People who have used PCs for longer (e.g office workers or gamers), can tell a difference up to 120/144 FPS. Hardcore gamers (e-sports, especially first person shooter games) can tell a difference up to ~240FPS. Any higher than that, brain/eyes won't register (which makes me wonder, why monitor manufacturers have produced 500+ Hz monitors, like this Asus Rog Swift Pro PG248QP, specs: https://rog.asus.com/monitors/23-to-24-5-inches/rog-swift-pro-pg248qp/ :unsure: ).

I consider myself a casual gamer (i used to be hardcore gamer back in the day) and i was able to tell a diff when i moved from 60Hz monitor to 144Hz monitor. On higher refresh rates/FPS, things (games), are a bit smoother but other that that, not much improvement. At least to my eye. Also, i don't care about FPS count in-games. As long as i get ~40FPS, i'm good. 30FPS is also doable but 20FPS is almost like a slide show.

anyway, there are no absolute facts about visual performance, the germans did research on perception of colour, eg synonyms, where eg yellow looks the same as red + green. its actually not the same, but its a trick of the mind.
Seeing colors is individual. Every person sees colors a bit differently. And some are colorblind (especially elderly people).
E.g i've had debates with my missus where i see blue-ish color while she sees green-ish color. In actuality, color was somewhere in-between the blue and green but based on how people see colors differently, doesn't make individual perceived observation wrong.

human hearing is on a different level from digital sound.
As seeing colors, hearing sounds is also individual. I prefer digital sound due to it's clarity. I especially like smooth, low bass (have almost maxed out my headset equalizer on 32 Hz, 64 Hz and 125 Hz ranges :sol: ). Also, since my favorite music gerne is Trance, which is purely digital music, it is best to listen it digitally.

I think I will go for this one, its just 74.56 more expensive, which is 2.76% extra price for the system.

https://uk.pcpartpicker.com/product...8-gb-ddr5-6600-cl32-memory-cmh96gx5m2b6600c32
(y)

if I were to upgrade the memory in the future, I'd remove the existing ones and buy a full new set fresh.
This is expensive but also the safest way to upgrade RAM. Most people can't afford it. Though, i've done it once, with Haswell build and cheap DDR3 RAM. Build initially came with 1x 8GB 1066 Mhz RAM. I replaced it by buying 2x 8GB 1866 Mhz RAM, while keeping the single stick in storage, as a backup, just in case. :)

if I go for 96GB, I reduce the risk of needing to increase the memory, and I push further into the future such a decision, where hopefully the price for a fresh new set will be much cheaper!
RAM is one such thing that as time moves onwards, it gets cheaper. Same with SSDs and HDDs too. CPU and MoBo prices usually remain same as they were at launch. But GPU and PSU prices usually rise. E.g my Seasonic PRIME 650 80+ Titanium PSU costed me €206.80 in 2016. But if i were to buy this PSU today, i'd be looking towards €350 or so.

safe overclocking, approved by the manufacturers of the mobo, cpu and memory module, where all guarantees are satisfied,

and unsafe overclocking, which you do at your own risk?
Yes.

RAM overclock profiles that are built-in to the DIMMs, are the "safe" ones, since RAM manufacturer has tested the RAM beforehand and fine-tuned the overclock profile (where frequency, timings and voltage values are playing nicely with each other). So, there is no harm to enabling built-in RAM overclock profile (EXPO/XMP).

There have been rare cases where built-in overclock profile doesn't work in specific system and RAM isn't stable. In this case, user can manually enter the frequency/timings/voltage to get the RAM stable. Usually by loosening the timings a bit does the trick. Or running lower frequency than what the RAM is rated for by built-in overclock profile.

does the mobo support HDMI to use initially?
No and Yes.

As i said, MoBo has 1x USB type-C port that supports DisplayPort 1.4. - Hence: "No".

Now, you can buy a cable that on one end is USB type-C and on another end is HDMI, if you want to connect HDMI display to the MoBo directly. - Hence: "Yes".


Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
I have moved some potentially off topic things to the end of the posting, with the most off topic stuff last.
with a note saying where the off topic comments start.

GPU prices rarely drop below MSRP. On the contrary, when new GPUs are launched, their price often rises over MSRP due to high demand.

potentially I should get the GPU now?

do you have a purchase link for the 4060?

possibly I can buy the 4060, but initially not install it, to assess what the system is like without the GPU.

then some weeks later install the GPU.


As of new GPUs to come, we are expecting Nvidia RTX 50-series around end of 2024, beginning of 2025.


All GPUs come with their own dedicated cooler that is designed to cool the GPU if no additional airflow is present. But additional airflow helps. Also, build i suggested does fine in terms of cooling, given that you go with Noctua fans and install all of them.


Most people have their vision between 30 and 60FPS. People who have used PCs for longer (e.g office workers or gamers), can tell a difference up to 120/144 FPS. Hardcore gamers (e-sports, especially first person shooter games) can tell a difference up to ~240FPS. Any higher than that, brain/eyes won't register (which makes me wonder, why monitor manufacturers have produced 500+ Hz monitors, like this Asus Rog Swift Pro PG248QP, specs: https://rog.asus.com/monitors/23-to-24-5-inches/rog-swift-pro-pg248qp/ :unsure: ).

I consider myself a casual gamer (i used to be hardcore gamer back in the day) and i was able to tell a diff when i moved from 60Hz monitor to 144Hz monitor. On higher refresh rates/FPS, things (games), are a bit smoother but other that that, not much improvement. At least to my eye. Also, i don't care about FPS count in-games. As long as i get ~40FPS, i'm good. 30FPS is also doable but 20FPS is almost like a slide show.


Seeing colors is individual. Every person sees colors a bit differently. And some are colorblind (especially elderly people).

I think colour blind people will discern a much higher frame rate, also their vision could be 3 x higher res in terms of area, squareroot(3)=1.732 ie 73.2% higher res linearly. because one cone per retina pixel, whereas with colour vision, 3 rods per pixel. colour blindness is better for low light, is higher resolution, and faster response.

if response time is important, the top people may well be colour blind!


(y)


This is expensive but also the safest way to upgrade RAM. Most people can't afford it. Though, i've done it once, with Haswell build and cheap DDR3 RAM. Build initially came with 1x 8GB 1066 Mhz RAM. I replaced it by buying 2x 8GB 1866 Mhz RAM, while keeping the single stick in storage, as a backup, just in case. :)
you could mitigate by purchasing the lowest capacity that you can tolerate, and then later going for the highest price that you can allow. this is a good MO, to go lowest end possible for something, then later go highest end viable where you junk the earlier purchase!

RAM is one such thing that as time moves onwards, it gets cheaper. Same with SSDs and HDDs too. CPU and MoBo prices usually remain same as they were at launch. But GPU and PSU prices usually rise. E.g my Seasonic PRIME 650 80+ Titanium PSU costed me €206.80 in 2016. But if i were to buy this PSU today, i'd be looking towards €350 or so.
I see a business opportunity here! buy such a PSU, keep it factory sealed, wait some years and sell it online, rake in healthy profits. that price rise looks like a viable business MO.

on ebay, if it is still good for today, people will fight to get factory sealed stuff from years ago

as soon as it is opened, its value will drop, you'll still sell it. dont try to remove any price labels from such items, because you can damage the underlying box. also keep the receipt to supply with the purchase.

you can then list it as new.


Yes.

RAM overclock profiles that are built-in to the DIMMs, are the "safe" ones, since RAM manufacturer has tested the RAM beforehand and fine-tuned the overclock profile (where frequency, timings and voltage values are playing nicely with each other). So, there is no harm to enabling built-in RAM overclock profile (EXPO/XMP).
ok, I am definitely getting the 2 x 48G option below 10ns, that seems an optimal decision, good value for money, top end speed, without dangerous overclocking.

I think I am ready now to start purchasing, I need to study my credit card balances also, as I think I just have some £3000 balance on one, where I want to keep some £1000 balance, thus I have to buy using different credit cards, in order to keep a reasonable balance on each. I dont use debit cards as these dont have the same protections.

as a different matter, I will have to study what further cables to get.

There have been rare cases where built-in overclock profile doesn't work in specific system and RAM isn't stable. In this case, user can manually enter the frequency/timings/voltage to get the RAM stable. Usually by loosening the timings a bit does the trick. Or running lower frequency than what the RAM is rated for by built-in overclock profile.


No and Yes.

As i said, MoBo has 1x USB type-C port that supports DisplayPort 1.4. - Hence: "No".

Now, you can buy a cable that on one end is USB type-C and on another end is HDMI, if you want to connect HDMI display to the MoBo directly. - Hence: "Yes".
do you have a purchase link for this?

my LG monitor is a 27UL500, https://www.lg.com/uk/monitors/uhd-4k-5k/27ul500-w/

at the back it has 2 HDMI sockets, and also a socket I dont recognise called DP-IN

can you recommend what cables to get for both the HDMI and for the DP-IN if it is relevant?

the current PC is in the next room in order to get silence, so the longest cable possible will be best,

eg I have a seriously long HDMI cable at the moment, but maybe I can use an adapter for that, so maybe also a recommendation for a converter adapter from USB type-C to HDMI to connect the existing HDMI cable to, which will handle the data speeds.

I will try the new PC in the same room to see if quiet enough, but otherwise it might go in the next room, with a cable through the wall to this room.

--------- POTENTIALLY OFF TOPIC COMMENTS FROM HERE ONWARDS and even more off topic comments later, I can edit these out on moderator request. ----------

E.g i've had debates with my missus where i see blue-ish color while she sees green-ish color. In actuality, color was somewhere in-between the blue and green but based on how people see colors differently, doesn't make individual perceived observation wrong.
I have had similar discussions with people, where I say something is one colour and they say its another colour! could be because some people have more green cones than blue, or other such imbalance. where the person is more sensitive to one colour component. and as you suggest, some cones might deteriorate with age, causing further imbalance. if you eat purple fruit or veg, you'll find your colour vision greatly improves. thus some deterioration is probably from poor nutrition, eg where many people dont eat salad and fruit. I eat purple cabbage every day. (sometimes called red cabbage). maybe each colour needs different nutrition!

in one era I took a lot of red grape juice, and noticed a big improvement in colour vision, where red grapes are kind of purple also. they arent red like a tomato! red wine also is kind of purple. it is debatable what colour as quite dark.

eg an object is red because it doesnt absorb red light, so to detect red light you need blue + green = cyan, where if you shine a red light it will look black because total absorption. potentially eating cyan colour food could improve red perception. there is a theory that with food, you should eat of the different colours. eg carrots for orange, tomatoes for red, sprouts for green, etc. the italians like to have the colours of their flag with their meals, where they will often arrange red + white + green items.

our chemistry teacher told us that light and colours are caused by temporary transitions of outer electrons of atoms to the next electron shell. so colour directly relates to chemistry. where colour may be more important for biology than we attribute.

the german experiments would shine a red lamp, green lamp, blue lamp of different intensities on the same spot, and then another 3 lamps with different intensities on another spot and ask them if they looked the same. by doing a lot of such tests on a lot of people, they arrived at an average for colour perception. where they have a mathematical model for the perception. this is from long before the computer era. and is used for colour profiles for say printers.

colour profiles enable a print from say an Epson, a print from a Canon and the image on screen to look the same. but you can never make 2 images exactly the same unless its the same "technology", eg 2 different Epson ecotanks could produce an identical image if they use the same ecotank ink. eg my old ET4550 ( think 4550) and the ET2660 (I think 2660), used identical ink. but my new ET16150 uses a totally different ink.

if you get ink by a different manufacturer, it is guaranteed to be different! (unless it is black ink for text!) there are online firms where you can purchase a colour profile for your specific inks and paper. where they send you a test image to print, which you post to them, and they email you a colour profile.

I have done this a few times, and also bought a home colour profiler called ColorMunki, probably better to use an online service instead.

when HP printers say "only use HP inks to get best colours", that is because they have profiled their inks, but if alternative inks are much cheaper, you just have to profile those, and you'll also get best colours.

I tend to only use the manufacturer's inks, and buy my Epson inks from Epson's website, as its the best prices.

with my samsung camera, which creates really lucid images. I once saw a very photogenic violet flower, photographed it, and compared the photo directly and it was the wrong colour! I think the photo was a dark blue. so they havent colour profiled it properly. but at the same time its a great camera, as really lucid images, and uses AA batteries, so is easy to rebattery.

for art and adverts etc, all that matters is an image looks good, doesnt matter if the colours are inaccurate.


As seeing colors, hearing sounds is also individual. I prefer digital sound due to it's clarity.

this is digressing a bit, but here goes:

that is probably because you havent heard a quality vinyl recording on a top end hifi separates system!

as that scene began vanishing around 1985 with the emergence of CDs.
if you sat in a hifi listening room for top end systems, you'd become obsessed with that instead.
people into this scene will generally be older than 55, most will be older than 60. so if you are younger than 55, I doubt you know this stuff.

the clarity of digital is because a lot of info is missing! where it sounds great for some music eg baroque music but is unsatisfactory when you have a wide gamut of simultaneous sounds, where you get noise.

digital sound loses info 2 ways, it discards between sample points on the x-axis, and then rounds to nearest quantum on y-axis. important point: human hearing isnt "additive" it is spectral, whereas digital sound is based on an additive assumption. thus when you hear a rich gamut of simultaneous sounds for real, it is a much richer sound than when it is digitised. because you have a hair in your ear for each frequency, that hair is unaffected by the sum of other frequencies. with digitisation a lot of those hairs are not stimulated.

basically human hearing is like having more than 3000 different primary colours, and not just 3. whereas digital sound is based on a sampling frequency of 1 specific colour. as the sampling frequency increases the quality will improve, but I found when I digitised my old cassettes with Audacity that the quality only became acceptable with huge audio files. and this was just to cope with 1 mm of cassette width per track!

CD quality was unacceptably substandard sound.

this is why sound is a much richer phenomenon than colour, each ear just listens to one pixel of sound, but with more than 3000 sound colours! the cochlea is basically a spectrometer for one pixel of sound, its on another level from digital sound which is mere amplitude sampling, the human ear is frequency sampling, with amplitudes for each of more than 3000 frequencies! your ear literally has more than 3000 cones of different colours for 1 pixel of sound. this is why you can listen to say 2 instruments playing and say: the one instrument is quiet, the other is loud, as this is a spectral assessment. humans have spectral analysis in hardware, stereo perception also allows us to spatially in 2D perceive each frequency.

there is no comparison, the main problem is digital sound is the work of engineers, 99.99999% of whom are clueless about zoology! the digital MO works better for images, as the eye cones are a kind of biological pixel, but also are different from computer pixels in that intensity is signal frequency, which is analogue. digital is a better match for the zoology of perceiving pictures than for sound. eye cones are binary, either on or off, but the brighter the light the faster the signals are sent.

analogue sound eg vinyl and magnetic tape is the only satisfactory approach as it has no frequency bias, other than a frequency response curve. master recordings were done I think with 24 track reel to reel tape.

digital music began emerging maybe 1980 with synthesizer music being used ever more.

the 1970s was the ultimate music era ever, digital music is a bit "cold". its good but is a cold sound.

when CDs first began appearing approx 1985, Dire Straits album "brothers in arms" was very popular because of the clarity. eg the Romeo and Juliet track:
View: https://www.youtube.com/watch?v=rC95MEenIxA


on a quality system that sounds much more metallic than in that video!

but if you listen to vinyl on a quality system, its a vastly richer gamut of sounds, like on a different level. most systems are garbage, where all CD decks sound better than most vinyl turntables, but if you get an upper range deck vinyl is vastly superior to CDs. you need to venture in the vanished hifi enthusiast scene to get to quality kit, eg I have a Dual CS505-mark 2 german deck from 1985, which won many accolades as the top midrange vinyl deck. eg it has a counterbalance which you have to set to perfectly balance the pressure of the needle. you balance perfectly and then add a small bias for perfect subtle needle pressure. and has belt drive, which means handles dirt better and less spurious sounds transmit from the mechanism to the deck. Also the playing deck has its own suspension within the outer deck. My brother has a Sony deck, and if you walk around the room the floorboards cause booming sound because it doesnt have proper suspension.

with the Dual, you wont get booming. also the Sony deck is direct drive, which isnt as good, its too "jumpy".

with the Dual, the motor turns a belt which indirectly turns the deck, this is much better engineering.


the Sony deck has very clear sound, but the Dual has vastly better midrange and lower frequencies. the japanese sensitivity to sound is upper frequencies, africans have sensitivity to lower frequencies, and europeans are midrange. when we were in Nigeria, this nigerian guy would say "your dad is arriving now", I asked "how do you know?", he said "I can hear his car". I couldnt hear anything and couldnt see the car out the window! then sure enough, a bit later my dad's car would appear in the distance. he could not only hear the car but could recognise which car, where I couldnt hear anything at all!

thus if you buy japanese kit, its usually good for upper frequencies, but no good for bass eg for reggae music, eg Pluto is great eg "dancing mood"
View: https://www.youtube.com/watch?v=rtxdk27nnrs


my turntable was german, amplifier and loudspeakers british, cassette deck japanese (TEAC) really great deck with CrO2 + dolby C: if you buy cassette decks today, no Dolby C, and no CrO2 + metal tape, just iron oxide. CrO2 + dolby C was as good sound as vinyl, metal tape even better but too expensive, a metal cassette was more expensive than a vinyl album! a CrO2 cassette track is literally 1mm wide, and outdoes CD. think of what quality a 1cm track would be! but they never allowed this because people would pirate everything! I found Sony to make the best CrO2 cassettes. TDK werent as good.

I especially like smooth, low bass (have almost maxed out my headset equalizer on 32 Hz, 64 Hz and 125 Hz ranges
:sol:
).

true hifi afficionados dont use equalisers!

:nan:


because all electronics adds distortion. some top end amplifiers just had on off switch and volume, not even bass or treble, because these add distortion. the concept is that perfection cannot be improved upon!

its like if you enhance a photo on Photoshop, information is in fact lost, you cannot in general get back to the original image. so I always keep the original unenhanced image as a mastercopy. now the photoshopped image can look vastly better.


I bought some Sony headphones once, and they had enhanced bass, so I junked them, because the enhanced bass wasnt the true sound. eg famous people on the radio's voices sounded incorrect! the voice would be impressive, but so modified it was a different voice! I had no option but to junk the headphones!


hifi = "high fidelity", and the concept isnt that things should sound good, but that the hifi sound should be identical to the original sound, not better, not worse, but the same! ie the replaying should have high fidelity with the original! its a lost art!

a google definition of fidelity is "the degree of exactness with which something is copied or reproduced." its not about the something being good but about being accurate.

your equalizers are like photoshopping, and are a no no for the hifi enthusiast!

non hifi people will push the bass and treble to max, but a hifi enthusiast will only move these from the midpoint to compensate for low quality loudspeakers. with quality kit you shouldnt use bass or treble or even worse equalisers as these add a whole row of distortions!

but you need to hear a top end system to properly understand, and I think those listening rooms have vanished, where they'd have the musical equivalent of Rolls Royces for the components.

the top turntables were german and scandinavian, british turntables were generally junk, but the british amplifiers and loudspeakers were top end. the best cassette deck I have heard is the japanese TEAC I bought, but for recording and playing CrO2, pre-recorded iron oxide cassettes arent proper hifi, you needed vinyl.

if you like bass, you ought to explore reggae, and explore beyond Bob Marley, eg Pluto is the best reggae musician in my opinion. I like the drumming of Selector's "on my radio",
View: https://www.youtube.com/watch?v=074AfC9tw48

which possibly isnt classed as reggae but is related.

but that sounds much better on a quality hifi system, with proper bass woofer speakers, as my cheaper computer speakers cannot cope with the lower bass of the drumming. quality loudspeakers will have at least woofers and tweeters, and usually the bigger the better for bass, although Bose specialised in making big loudspeaker sound from small loudspeakers. my loudspeakers are big (not ginormous) by a small british firm, H53cm x W27cm x D26cm, where they have a hole at the back to allow air to flow out from lower bass sounds!

the turntable's recommended diamond needles by a specialised danish firm are still available new online, I think for about £50.

if I connect my PC's audio output to an input of my old amplifier, I can listen to my audacity recordings on my 1985 hifi system, and with a much higher sampling rate than CDs it is good.


Also, since my favorite music gerne is Trance, which is purely digital music, it is best to listen it digitally.
do you like KLF 3am eternal?
View: https://www.youtube.com/watch?v=HDsCeC6f0zc


Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
48GB stick. Namely 2x 48GB kit.


2x 48GB (96GB), 6600 Mhz, CL32, 9.697ns, £331.05, £3.448 per GB, pcpp: https://uk.pcpartpicker.com/product...8-gb-ddr5-6600-cl32-memory-cmh96gx5m2b6600c32

ok, I have ordered most of the config, the earliest for the PSU from amazon was 6th feb, so that one item I got on ebay, I hope I got the right PSU:

https://www.ebay.co.uk/itm/305011358735

the other items I bought from the links you gave,


I bought the 96GB memory in the link above, but then as writing this message found you gave a wrong link! and in fact I had bought 2 x 16GB to arrive Monday, but I have managed to correct that!

the text of your link does say 96-gb-2-x-48-gb

but if you click the amazon link you will find it is in fact 2 x 16GB!

I dont know if you can troubleshoot that link and find what the correct link is!

The Corsair link for that is correct, I might buy directly from Corsair but will wait till you reply, I havent found the delivery time at that URL.

I bought also the 10 x USB3.0 hub, and the internal USB header for the new mobo.

it was a really complicated purchase, as I was trying to add to basket for amazon ones.

my credit card also blocked the purchase for the mobo, because I was making too many expensive purchases too quickly! but I cleared that with the credit card, it cost me in fact 728, from morecoco

scan s is good, they will deliver their item tomorrow! superfast at no extra price, and I opted in for product protection for some £3 which includes installation errors

Last edited:

Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
2x 48GB (96GB), 6600 Mhz, CL32, 9.697ns, £331.05, £3.448 per GB, pcpp: https://uk.pcpartpicker.com/product...8-gb-ddr5-6600-cl32-memory-cmh96gx5m2b6600c32

maybe the amazon link is alright after all! my amazon purchase list itemised the purchase as 2 x 16GB, but I see now that in the amazon page from the above URL, there is a box saying 96GB (2 x 48GB), where its probably just a confusing listing.

the listing shouldnt say 2 x 16GB if it has 3 other options, namely 2 x 32GB, 4 x 16GB and 2 x 48GB

it ought to just say:

"Corsair VENGEANCE RGB DDR5 6200MHz C36 Intel Optimised Desktop Memory (Dynamic Ten-Zone RGB Lighting, Onboard Voltage Regulation, Custom XMP 3.0 Profiles, Tight Response Times) White "

and not the following where I have put in purple font the confusing bit:

"Corsair VENGEANCE RGB DDR5 32GB (2x16GB) 6200MHz C36 Intel Optimised Desktop Memory (Dynamic Ten-Zone RGB Lighting, Onboard Voltage Regulation, Custom XMP 3.0 Profiles, Tight Response Times) White"

I probably should reorder that order I cancelled!

I'll delay till later tonight, and see if any comments on this, then reorder it.


it literally took me a few hours to do that initial purchasing! as I had to keep going through the payment security, and recalculate the amount of credit I have left on the different credit cards.


Aeacus

Titan
Ambassador
do you have a purchase link for the 4060?
Sure, amazon UK: https://www.amazon.co.uk/dp/B0C7WCKXB6

Note: There are in total of 73 variants of RTX 4060. Full list here (scroll down): https://www.techpowerup.com/gpu-specs/geforce-rtx-4060.c4107

The link i gave is MSI Gaming X version, which is high-end version of RTX 4060. MSI Gaming X GPUs are known for their great cooling and quiet operation. E.g GPU has a Zero Frozr feature, where when GPU is below 60C, GPU fans won't spin at all.
This is also one of the reasons why i use MSI Gaming X GPUs for myself.

I see a business opportunity here! buy such a PSU, keep it factory sealed, wait some years and sell it online, rake in healthy profits. that price rise looks like a viable business MO.
This idea doesn't quite work, since any PSU you sell, is without warranty. And without warranty, at least for me, price is 50% of MSRP, regardless if the PSU is used or not.
Also, buying used PSUs is really bad idea.

Though, scalpers have done it with GPUs, especially RTX 30-series. Once RTX 30-series launched, automated bots of scalpers bought GPUs in bulk from anywhere they could. Same was with cryptocurrency miners, who bought the consumer GPUs en masse. Once stock ran out in retail stores, scalpers put the GPUs on sale with 2-3 times of MSRP (Manufacturer Suggested Retail Price). And since there were desperate people who wanted better GPU, many also bought those GPUs at insanely high prices. There were also a lot of people who had built their PC but were missing a GPU, since they didn't have the money to pay 2-3 times the MSRP for a GPU.

GPU manufacturers did try to help out consumers by producing LHR versions of GPUs. Meaning that LHR (Low Has Rate) GPU is far weaker at cryptocurrency mining but for gaming use, performance didn't drop, so that consumers still have a product to buy.

GPU manufacturers also started to limit the sales. E.g EVGA only sold 1-2 GPUs per person, so that scalper/miner can't buy out entire stock.

Thing got even so bad, that entire truckload of RTX 30-series GPUs were stolen, when truck traveled from factory to distribution center,
article: https://www.pcmag.com/news/someone-in-california-stole-a-bunch-of-pc-graphics-cards-from-evga
follow-up: https://www.pcmag.com/news/months-after-heist-stolen-evga-graphics-cards-appear-in-vietnam

At some point, there was cryptocurrency crash, whereby mining the coins didn't yield any profits anymore. Also, cryptocurrency algorithm was reworked where one can't use consumer GPUs anymore. So, there was (and still is), huge surplus of used RTX 30-series GPUs on 2nd hand market currently. Now, only select few GPUs can mine cryptocurrency. E.g purpose built mining GPUs, that won't see retail sales and can be bought from manufacturer directly, in bulk. Or one needs to use CPU to mine the cryptocurrency, which is FAR slower than using a GPU.

Now, scalpers did try the same with RTX 40-series as well, when RTX 4090 and then 4080 launched. RTX 4090 is so expensive, that there is little market for it. And when RTX 4080 launched, it's performance gain over RTX 30-series was so little that consumers didn't want to buy RTX 4080 GPUs at all, let alone from scalpers with insanely high prices. So, scalpers were stuck holding GPUs that no-one wanted.
Article: https://www.techspot.com/news/96837-scalpers-struggle-sell-rtx-4080-above-msrp-but.html

So, idea of buying out stock and then selling it at far higher prices, won't work with GPUs anymore. And it won't work with PSUs either, since PSU market is far bigger than GPU market and there are plenty of options which brand of a PSU to buy.

Let's say you have funds to buy out entire stock of Corsair 650W models, which include: CX, CXm, CXf, RM, RMe, RMi, RMx series of GPUs. What consumer can do, is switch brand and buy e.g Seasonic 650W unit instead. Now, if you have even more funds to buy out Seasonic 650W units as well, which include: S12III, B12 BC, B12 BM, Core GC, Core GM, Core GX, Focus GM, Focus GX, Focus PX, PRIME GX, PRIME PX, PRIME TX; then consumer can switch brand again and buy Super Flower 650W unit. Or they can buy Corsair 750W or Seasonic 750W unit instead. Extra 100W capacity on PSU doesn't hurt the efficiency that much.

With GPUs, it was simpler to buy out stock since there is only one manufacturer: Nvidia (or two if you also count AMD Radeon). And SKUs per series are also limited: e.g Nvidia RTX 3050, 3060, 3070, 3080 and 3090.
Each new GPU release is well anticipated and there are many people who want the latest and greatest when it comes to GPUs. So, with limited manufacture and stock, it was relatively easy for scalpers to buy out entire stock. Also, back then, there were no policies in place where one could buy 1-2 GPUs per person.

PSU market is far more diversified and there are far more OEMs + countless PSU brands (e.g Corsair, EVGA, XFX, Thermaltake etc etc).
PSU OEMs by founding year (not complete list):
1969 Flextronics (Flex)
1971 Delta Electronics
1975 Seasonic
1979 HEC Compucase
1986 Enhance Electronics
1989 Great Wall (China GreatWall Technology Group Co., Ltd. subsidiary of China Electronics Corporation)
1990 Enermax
1991 Super Flower
1991 Sirtec Electronics
1993 FSP Group
1993 Channel Well Technology (aka CWT)
1996 Sirfa (SIRFA Electronics Co., Ltd)
1997 Andyson
2008 High Power (aka Sirfa, aka Sirtec)

Some of those OEMs are great build quality wise, like: Flextronics, Seasonic and Super Flower. Then there are those who have huge production facilities, like: Great Wall and Channel Well Technology. Of course, this list above includes most known OEMs in PSU world, but there are other PSU OEMs as well, like: RSY, Shenzhenshi Jiumeng Electronics Technology Co.,ltd. (uses the brand of Aresgame) etc. Though, bulk of crap quality PSUs are made by no-name OEMs (usually from China).

So, good luck if you want to scalp the PSU. :rofl:

do you have a purchase link for this?

my LG monitor is a 27UL500, https://www.lg.com/uk/monitors/uhd-4k-5k/27ul500-w/

at the back it has 2 HDMI sockets, and also a socket I dont recognise called DP-IN

can you recommend what cables to get for both the HDMI and for the DP-IN if it is relevant?
Your monitor has two HDMI input ports and one DisplayPort input port. DP = DisplayPort.

So, for a cable to monitor, all you'd need is USB type-C to DP or HDMI.

E.g USB type-C to HDMI, amazon UK: https://www.amazon.co.uk/CableCreation-Thunderbolt-Compatible-MacBook-Chromebook/dp/B06XDMKQKJ
or USB type-C to HDMI 16 feet, amazon UK: https://www.amazon.co.uk/CableCreation-Cable-Apple-Macbook-Chromebook/dp/B015RIVYJK
or USB type-C to DP, amazon UK: https://www.amazon.co.uk/DisplayPort-uni-Compatible-MacBook-Surface/dp/B075V27G2R/

As far as HDMI vs DP, overall, there is no difference.
HDMI was created for TVs and most TVs have only HDMI input port.
DP (DisplayPort) was created for computer monitors and hence why computer monitors have DP input port. Many also have HDMI input port for versatility.

Main diff with HDMI and DP is, that there are different revisions of HDMI and to use newer version of HDMI, you have to use compatible cable that supports newer version of HDMI. With DP, there is no such issue with cables. DP cable that was created when DP 1.1 was out, will work fine with latest, DP 1.4 as well.
Small article to explain the diff between HDMI and DP,
link: https://www.rtings.com/monitor/learn/hdmi-vs-displayport

I bought the 96GB memory in the link above, but then as writing this message found you gave a wrong link! and in fact I had bought 2 x 16GB to arrive Monday, but I have managed to correct that!

the text of your link does say 96-gb-2-x-48-gb

but if you click the amazon link you will find it is in fact 2 x 16GB!

I dont know if you can troubleshoot that link and find what the correct link is!

The Corsair link for that is correct, I might buy directly from Corsair.
The link is actually correct. Look closely the 4 choices amazon offers. You'll see that the 2x 48GB option is selected when you link to the amazon page.
Circled it:




my amazon purchase list itemised the purchase as 2 x 16GB, but I see now that in the amazon page from the above URL, there is a box saying 96GB (2 x 48GB), where its probably just a confusing listing.
I see that you catched the error in listing. (y)


------------------------------------
I'll keep replying to your off-topic comments at minimum, since we already got one warning.
------------------------------------
that is probably because you havent heard a quality vinyl recording on a top end hifi separates system!
I've heard some but like i said, i like electronic music.

Best example would be one of my all time most favorite tracks;
Saltwater - The Legacy (Alphazone mix)

View: https://www.youtube.com/watch?v=pfkGLQTC3GU


It has a long intro, ~3.5 mins. Also, i love the talking it it. A great track to listen and relax. I get mezmerized by it. :giggle:

true hifi afficionados dont use equalisers!

:nan:
I'm not audiophile so, i don't care about "true/pure" audio what analog hardware can output. I'm happy with my digital era music. :)

if you like bass, you ought to explore reggae
I don't like reggae. Not my cup of tea.

An example of what kind of "bass" i like;
DuMonde - See The Light (Video edit)

View: https://www.youtube.com/watch?v=ERcg2XD7XLI


Original track is twice as long, but for sample, this video version will do. :)

do you like KLF 3am eternal?
I'm not into rap music. Though, intro sounded like trance track but once singing start, it is a rap song in it's core. Sure, there are elements of disco but overall i don't like the rapping part. Instrumental version of it would be better to listen to.

I would just like to note, I have never seen such long and comprehensive posts in a back-and-forth go for as long as this in all my time on Tom's. Good luck on your build @Richard1234 and goo on yah @Aeacus. The commitment is commendable here. Anyways, carry on!
Dedication. :sol:

  • Like
Reactions: 35below0

Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
Sure, amazon UK: https://www.amazon.co.uk/dp/B0C7WCKXB6

Note: There are in total of 73 variants of RTX 4060. Full list here (scroll down): https://www.techpowerup.com/gpu-specs/geforce-rtx-4060.c4107

The link i gave is MSI Gaming X version, which is high-end version of RTX 4060. MSI Gaming X GPUs are known for their great cooling and quiet operation. E.g GPU has a Zero Frozr feature, where when GPU is below 60C, GPU fans won't spin at all.
This is also one of the reasons why i use MSI Gaming X GPUs for myself.
I have purchased it now, using yet another credit card! arranged for it to be delivered to an amazon locker, I should have done that with the earlier orders, but they dont make that option very visible. after hours of making purchases, I am not reading info properly.

I have now ordered the 96GB memory, but then forgot to do the amazon locker, so cancelled and repurchased, and this time it said that locker is full! so I cancelled, and tried again, with a different locker, that one also full. so tried again, this time said I couldnt use that card, later got a fraud control text, had I tried to make several purchases! so tried yet again to my home address with a 4th credit card, and that succeeded!

I have never cancelled and repurchased the same item as many times as that 96Gig memory!

they should give you a cooling off time after a purchase to completely rejig the transaction, eg change the payment method, the delivery address etc.


This idea doesn't quite work, since any PSU you sell, is without warranty. And without warranty, at least for me, price is 50% of MSRP, regardless if the PSU is used or not.
I dont know what the rules are for what defines an end user, couldnt the customer try their ebay receipt as evidence that they bought new?

for some new things there isnt a warranty, eg books, you just have to preserve the book in new condition.


Your monitor has two HDMI input ports and one DisplayPort input port. DP = DisplayPort.

So, for a cable to monitor, all you'd need is USB type-C to DP or HDMI.

E.g USB type-C to HDMI, amazon UK: https://www.amazon.co.uk/CableCreation-Thunderbolt-Compatible-MacBook-Chromebook/dp/B06XDMKQKJ
or USB type-C to HDMI 16 feet, amazon UK: https://www.amazon.co.uk/CableCreation-Cable-Apple-Macbook-Chromebook/dp/B015RIVYJK

this is the only one long enough, 2m would be too short, 16 foot would be alright. the snag is earliest delivery is 10th feb. unless I install the graphics card, does that have an HDMI socket?
https://www.amazon.co.uk/CableCreation-Cable-Apple-Macbook-Chromebook/dp/B015RIVYJK
this particular one is too short at 1.8m,


As far as HDMI vs DP, overall, there is no difference.
HDMI was created for TVs and most TVs have only HDMI input port.
DP (DisplayPort) was created for computer monitors and hence why computer monitors have DP input port. Many also have HDMI input port for versatility.

Main diff with HDMI and DP is, that there are different revisions of HDMI and to use newer version of HDMI, you have to use compatible cable that supports newer version of HDMI. With DP, there is no such issue with cables. DP cable that was created when DP 1.1 was out, will work fine with latest, DP 1.4 as well.
Small article to explain the diff between HDMI and DP,
link: https://www.rtings.com/monitor/learn/hdmi-vs-displayport

if there isnt much difference, HDMI would be better as I can use HDMI on many machines!

what do you think of that LG monitor? I got talked into it, and am not convinced its a good monitor.

The link is actually correct. Look closely the 4 choices amazon offers. You'll see that the 2x 48GB option is selected when you link to the amazon page.
Circled it:





I see that you catched the error in listing. (y)


------------------------------------
I'll keep replying to your off-topic comments at minimum, since we already got one warning.
------------------------------------

I've heard some but like i said, i like electronic music.

Best example would be one of my all time most favorite tracks;
Saltwater - The Legacy (Alphazone mix)

View: https://www.youtube.com/watch?v=pfkGLQTC3GU


It has a long intro, ~3.5 mins. Also, i love the talking it it. A great track to listen and relax. I get mezmerized by it. :giggle:


I'm not audiophile so, i don't care about "true/pure" audio what analog hardware can output. I'm happy with my digital era music. :)
what you dont know you cant miss!

this is the scary thing for me in my late 50s, that things which were central to society when I was a kid and a teenager and even in my 20s etc are invisible to the young people of today! the thing is the things which are central today will also be completely forgotten in a few decades!

I had a listen to those 2, the sound is interesting, its what I'd call mood music, like with other digital music its a "cold" feel. its good but also cold.

on the cold side, with the 1970s there was say Jean Michelle Jarre, eg Oxygene,
View: https://www.youtube.com/watch?v=5ab7tIZNplM


this is early era electronic music.

Giorgio Moroder was one of the earliest innovators of electronic music, eg with the famous Donna Summer hits, eg "I feel love" which was 1977.

View: https://www.youtube.com/watch?v=9ZqqvrWCs3Q


all your trance music originates from this kind of music from this part of the later 1970s, where the music is going round and round and round, and is a kind of mood


I don't like reggae. Not my cup of tea.

with all new forms of music, you need to listen for some hours,

the music we like is because we listened to it enough times that we eventually accept it just from repetition!

you will accept any music genre at all if you listen to it enough!

all culture is relative and arbitrary!

when I got my hifi in 1985, I listened to albums from a college record library of diverse genres of music, and first listening to a new group, often not that interested, but as you replay the music, it starts to grow on you.

An example of what kind of "bass" i like;
DuMonde - See The Light (Video edit)

View: https://www.youtube.com/watch?v=ERcg2XD7XLI


Original track is twice as long, but for sample, this video version will do. :)


I'm not into rap music. Though, intro sounded like trance track but once singing start, it is a rap song in it's core. Sure, there are elements of disco but overall i don't like the rapping part. Instrumental version of it would be better to listen to.

that KLF music is maybe 1990

its difficult to categorise, its not true disco, as disco is more the latter 1970s, ie its the wrong decade! and its not true rapping, true rapping is where it is more like a rhyming dialogue slightly confrontational, where it is primarily alternating talk by 2 singers which clashes a bit, an innovative version of rap music was "queen of the rapping scene" by Modern Romance:

View: https://www.youtube.com/watch?v=-w6sDTwZatg


I agree that part of it could maybe be categorised as rapping, its what you might call a rapping derivative.

I think the trance music is maybe 2nd half of the 1980s, often for drug based gigs, eg raves, where they have flashing lights and take drugs such as speed and ecstasy

in my opinion KLF isnt a specific category but they were drawing on different musical genres of the time, which look like they include rapping and trance music,


Aeacus

Titan
Ambassador
I dont know what the rules are for what defines an end user, couldnt the customer try their ebay receipt as evidence that they bought new?
When it comes to electronics and their warranty, for seller to uphold warranty, they have to provide returns for customers, among other things.

Now, you buying a PSU from officially licensed retailer means, that when PSU develops a manufacturing fault, you can return the PSU to the store within the warranty period and it's the store who has to deal with it then. Usually store sends the PSU to the manufacturer and depending on what manufacturer decides, either the manufacturer sends a replacement unit to the store, or sends the broken PSU back, if it is found out that fault was caused by user error (e.g overloading the PSU by connecting way too much stuff to it).

But if you were to sell the PSU you bought from retail store, on Ebay, then this is a private transaction between two parties. You have 0 obligations to provide further customer support to whomever you sold the PSU to. Hence why you can't include warranty with the PSU.

Some PSU manufacturers might uphold the warranty, IF the warranty claim is done by the person who initially bought the PSU, given that they have invoice to prove the purchase. E.g Seasonic is the only one in PSU industry who does that. Others won't.

I can put it also via the buyer perspective;
What incentive there is for me, to buy PSU from you, via Ebay? Even if PSU manufacturer upholds the warranty, when i have an issue with PSU, i have to track you down, so that you can do the warranty claim on my behalf (since you bought it from the retail store and you are the one who holds the warranty). Probably need to ship the broken PSU to you as well. And replacement PSU is sent to you, which you then have to ship it to me.
All this hassle and for what? Far easier is for me to go to my local store and buy the PSU from there, so, i'm the one who holds the warranty. And if issues arise, i can easily go back to the local store to turn the PSU in.
And if you sell the PSU more than MSRP, then it's even worse for me, since it's loose-loose situation for me. Paying more + the hassle with RMA. Also, i don't think that you'd like when i bother you 2, 5, 7, 9 or 11 years later with the PSU you sold to me (given that i bought Seasonic unit from you with 12 years of warranty).

for some new things there isnt a warranty, eg books, you just have to preserve the book in new condition.
Yes, not all items have warranty. Groceries (food stuff), incandescent light bulbs and custom made orders (e.g tailored suit) are the ones that come to my mind. But all electronics have warranty, including LED light bulbs.

Of course, warranty policy differs around the world. EU has it simple, either 14 day "cool-off" period or minimum of 2 years warranty,
further reading: https://europa.eu/youreurope/citizens/consumers/shopping/guarantees-returns/index_en.htm

How warranty policies are in e.g USA or UK, i don't know. Need to read local laws about that.

does that have an HDMI socket?
Yes, it does. It has 1x HDMI port and 3x DP ports,
GPU specs: https://www.msi.com/Graphics-Card/GeForce-RTX-4060-GAMING-X-8G

what do you think of that LG monitor? I got talked into it, and am not convinced its a good monitor.
It's poor monitor.

Sure, it is 4K monitor but able to only deliver 60Hz. Also, panel type is IPS and while IPS does have the best color accuracy out of the three main panel types (other two being TN and VA), it also has terrible contrast ratio. 1000:1 (or minimum of 700:1 as seen on specs). It also has poor response time of 5ms. It's size of 27" is also a bit small, since 4K monitors usually are 32" and bigger. For 27", 1440p (2K) would be better. And only tilt can be adjusted.

Also, your monitor specs are lying. E.g on the specs, it is said that your monitor has HDR10. Well, this isn't true, since for HDR10, monitor must be capable to output 1000 nits (or cd/m2) of brightness, while your monitor is only able to output up to 300 nits, with 270 nits as minimum. Heck, it even doesn't reach HDR levels, since at bare minimum, HDR requires 400 nits.

SDR - 100 nits
HDR - at least 400 nits
HDR10 - 1000 to 4000 nits
HDR10+ - 10000 nits

For comparison, my MSI MAG Optix241CR monitor, specs: https://www.msi.com/Monitor/Optix-MAG241CR/Specification
Is: 23.6", 1080p, 144Hz, VA panel, curved, 3000:1 contrast ratio, 1ms response time and i can adjust tilt and height.


More about monitor panels;
To pick a monitor, it's good when you know more about different monitor panel types. There are 3x kinds of monitor panels: TN, VA and IPS. Actually there are more (variations of the main three) but i focus on these main ones.

TN panel is oldest of the three and also cheapest. Where TN panel excels is it's performance, most notably response time (1ms).
Though, TN panel also has it's downsides. Prominent ones are: poor color accuracy (washed out colors), very narrow view angle and poor contrast ratio (max 1000:1).

Gaming wise, TN panel monitor is best suited for fast-paced games (FPS, racing etc), where you don't care as much about pretty colors as you do about smoothness of movements.

IPS panel has been around for some time and is also the most expensive of the three.
Where IPS panel excels is it's color accuracy, which is the best of the three. Also, it has widest viewing angles of the three.
But where IPS panel falls short is response time. IPS technology by design can't be any faster than 4ms (compared to the 1ms most TN panels are). Another area where IPS panel falls short is it's poor contrast ratio which is equal to a TN panel (max 1000:1), despite it's great color accuracy. This is most prominent when looking at black image and where black isn't black but instead gray or some form of blue. Refresh rates aren't IPS panel strong side either and many IPS panels are 60Hz, especially on higher resolutions. There are some 1440p 165Hz and 4K 120Hz IPS panel monitors out there but they are few and far apart, also costing a fortune.

Gaming wise, IPS panel monitor is best suited for slow-paced games (RPG, strategy etc), where you have time to see all those pretty colors and where smoothness of movements isn't that important.

VA panel is the newest of the three and price wise, it falls between TN and IPS. VA panel was created to take the best of both worlds (TN and IPS) and combine them.
Where VA panel excels is it's contrast ratio (min 3000:1), where you'd see the deepest and richest blacks. Also, it doesn't fall short on other aspects as well. VA panel color accuracy isn't as good as it is for IPS panel but it's close to the levels of IPS panel (considerably better than TN panel). It's viewing angle is also a notch smaller than that of an IPS panel but again, considerably better than that of a TN panel. Refresh rate wise, VA panel is more capable on different resolutions than IPS panel. Response time is another area where VA panel does good. While VA panel can't naturally be any faster than 4ms (just like IPS panel), it can achieve the magical 1ms response thanks to the software solution in it.
With VA panel monitors making waves lately, there aren't any major downsides of them. Availability used to be issue but not anymore.

Gaming wise, VA panel monitor is suited for all kinds of games. VA panel is like Jack of all trades but master of none (except when it comes to contrast ratio, there, VA panel is king).

I had a listen to those 2, the sound is interesting, its what I'd call mood music, like with other digital music its a "cold" feel. its good but also cold.

on the cold side, with the 1970s there was say Jean Michelle Jarre, eg Oxygene,
this is early era electronic music.

Giorgio Moroder was one of the earliest innovators of electronic music, eg with the famous Donna Summer hits, eg "I feel love" which was 1977.
all your trance music originates from this kind of music from this part of the later 1970s, where the music is going round and round and round, and is a kind of mood
Yes, i know the electronic music pioneers and i sometimes listen to them. E.g "Jean Michelle Jarre - Oxygene part 4" i do like.

I think the trance music is maybe 2nd half of the 1980s, often for drug based gigs, eg raves, where they have flashing lights and take drugs such as speed and ecstasy
Not quite. On the raves, there was different form of electronic music. Initially called EDM (Electronic Dance Music), but many genres did grow out of it. Nowadays, raves usually play "Hard Dance" and it's sub-genres, like Hard Acid Trance, Hard Trance and especially Hardstyle.

Example of Hardstyle;

View: https://www.youtube.com/watch?v=iZVnG7z7xp0


The trance i like to listen to, is Classic Trance and "Eurotrance" and it's sub-genres: Dream Trance, Anthem Trance and especially Epic (Euphoric) Trance. "Saltwater - The Legacy (Alphazone mix)" i linked before is Epic Trance.
Oh, from time-to-time, i also like to listen PSY Trance, namely Goa Trance and Psychedelic Trance.

Example of Psychedelic Trance;

View: https://www.youtube.com/watch?v=T2fj3FOsg0Q


The one in red cap is Raja Ram, one of the forerunners in Psychedelic Trance scene. Still active to this day, at age 83.

  • Like
Reactions: 35below0

Richard1234

Distinguished
Aug 18, 2016
277
5
18,685
my amazon purchase list itemised the purchase as 2 x 16GB, but I see now that in the amazon page from the above URL, there is a box saying 96GB (2 x 48GB), where its probably just a confusing listing.

quote:
> I see that you catched the error in listing. (y)

to understand the confusion, here is a screenshot of my purchase:

http://www.directemails.info/tom/memory.jpg

looking at that, what would you say I had bought?

doesnt look like 96GB even though it is. that's why I cancelled it.

the problem now is the Monday delivery has become a Wednesday delivery.


Of course, warranty policy differs around the world. EU has it simple, either 14 day "cool-off" period or minimum of 2 years warranty,
further reading: https://europa.eu/youreurope/citizens/consumers/shopping/guarantees-returns/index_en.htm

How warranty policies are in e.g USA or UK, i don't know. Need to read local laws about that.

it might depend on the shop in the UK, I had a problem with a USB drive years ago from Staples, which is a big US firm, and they said I have to contact the manufacturer, nothing to do with them. A lot of UK warranty claims are via the manufacturer, not the shop.

furthermore, Domestic & General and also DSG will sell their own warranties and extended warranties, where warranty claims go via them and not via the shop.


its possible that they can defer to the manufacturer if their terms and conditions say this. all businesses need to have terms and conditions, otherwise default statutory ones apply.


there are 2 forms of contract laws:

1. default laws. these laws can be overridden but only with a contract. the firm can opt out.
2. overriding laws, these override whatever a contract says. the firm cannot opt out.

I think the 14 days cooling off law is probably 2., but the warranty claims handled by seller are probably 1.

the 2 years law is probably 2. where basically you have to have 14 days cooling off and 2 years warranty, but a seller could defer warranty claims to the manufacturer if its in their terms and conditions.

a seller or manufacturer could also extend the 2 years.

where you quoted the laws, you have to scrutinise the laws more carefully as to whether they are 1. or 2.

with 2. a term or condition which overrides the law is an illegal term or condition, whereas with 1. its ok.


in the UK, if you phone "citizens advice bureau", they will say the specific rules.

when Maplins went bankrupt, they said no refunds and no handling of the guarantees, go to the manufacturer. so there are exemptions to 14 day cooling off for insolvency sales.

with such bankruptcy sales, when you go to pay they warn you that no customer support or refunds, ie if you override the law, you need to make this blatant.

the probs you mentioned the PSU manufacturer faced, are because they would seem to be profiteering, and so others then try to get in on the racket. anything which rises faster than inflation is profiteering, and people will try to get in on the act. they then get into a fight trying to ration the items, because they dont want others joining the profiteering.

its like if a place has rats, you shouldnt blame the rats, you only get rats if you have a hygiene problem. rats arent interested in fresh food, as their digestive system is too weak. if you have rats, its because there is bad stuff the rats want.

sometimes the manufacturers are involved in the racket, eg games consoles creating artificial scarcity, and pop concert tickets going to ticket touts, where they have an official price eg £20, but the tickets sell out instantly, in fact going to touts, and the touts sell them for say £50. but the people managing the tickets then get a backhander from the £50 from the touts. but then external people want to get in on the racket.

this kind of thing is probably categorised as racketeering, and is probably illegal, but is difficult to stop, as you'd have to show evidence of motive and conspiracy. the racketeers will have a cover story which is difficult to refute. eg they might make the tickets available immediately after the announcement, where the touts can buy everything up before the fans have organised themselves to buy a ticket! because they got forewarned. so technically nothing illegal.

also the law enforcers might be involved in the racket! its basically fraud, but fraud is civil law, so the police cant do anything, and in court you have to show the deception is deliberate and not unintended, and the legal fees will be at least £25000, which means you cant do anything about a £50 fraud, except via class action lawsuits. the police cannot do anything as its civil law.


Yes, it does. It has 1x HDMI port and 3x DP ports,
GPU specs: https://www.msi.com/Graphics-Card/GeForce-RTX-4060-GAMING-X-8G

that does mean I can maybe install the graphics card and use the existing HDMI cable, I just dont know if that cable will handle the higher quality signal, but I can use it provisionally.

You said earlier:

> So, for a cable to monitor, all you'd need is USB type-C to DP or HDMI.

but why not USB type A to DP or HDMI?



It's poor monitor.
this is what I suspected, as I found the image worse than my passive 3D monitor, I think from around 2008.

there is something a bit blurry about the image. it lacks the pixel perfect image of my other LG.

I think the passive 3D LG must have more advanced pixels to handle twin images via polarisation.

Sure, it is 4K monitor but able to only deliver 60Hz. Also, panel type is IPS and while IPS does have the best color accuracy out of the three main panel types (other two being TN and VA), it also has terrible contrast ratio. 1000:1 (or minimum of 700:1 as seen on specs). It also has poor response time of 5ms. It's size of 27" is also a bit small, since 4K monitors usually are 32" and bigger. For 27", 1440p (2K) would be better. And only tilt can be adjusted.

Also, your monitor specs are lying. E.g on the specs, it is said that your monitor has HDR10. Well, this isn't true, since for HDR10, monitor must be capable to output 1000 nits (or cd/m2) of brightness, while your monitor is only able to output up to 300 nits, with 270 nits as minimum. Heck, it even doesn't reach HDR levels, since at bare minimum, HDR requires 400 nits.

SDR - 100 nits
HDR - at least 400 nits
HDR10 - 1000 to 4000 nits
HDR10+ - 10000 nits

For comparison, my MSI MAG Optix241CR monitor, specs: https://www.msi.com/Monitor/Optix-MAG241CR/Specification
Is: 23.6", 1080p, 144Hz, VA panel, curved, 3000:1 contrast ratio, 1ms response time and i can adjust tilt and height.


More about monitor panels;
To pick a monitor, it's good when you know more about different monitor panel types. There are 3x kinds of monitor panels: TN, VA and IPS. Actually there are more (variations of the main three) but i focus on these main ones.

TN panel is oldest of the three and also cheapest. Where TN panel excels is it's performance, most notably response time (1ms).
Though, TN panel also has it's downsides. Prominent ones are: poor color accuracy (washed out colors), very narrow view angle and poor contrast ratio (max 1000:1).

Gaming wise, TN panel monitor is best suited for fast-paced games (FPS, racing etc), where you don't care as much about pretty colors as you do about smoothness of movements.

IPS panel has been around for some time and is also the most expensive of the three.
Where IPS panel excels is it's color accuracy, which is the best of the three. Also, it has widest viewing angles of the three.
But where IPS panel falls short is response time. IPS technology by design can't be any faster than 4ms (compared to the 1ms most TN panels are). Another area where IPS panel falls short is it's poor contrast ratio which is equal to a TN panel (max 1000:1), despite it's great color accuracy. This is most prominent when looking at black image and where black isn't black but instead gray or some form of blue. Refresh rates aren't IPS panel strong side either and many IPS panels are 60Hz, especially on higher resolutions. There are some 1440p 165Hz and 4K 120Hz IPS panel monitors out there but they are few and far apart, also costing a fortune.

Gaming wise, IPS panel monitor is best suited for slow-paced games (RPG, strategy etc), where you have time to see all those pretty colors and where smoothness of movements isn't that important.

VA panel is the newest of the three and price wise, it falls between TN and IPS. VA panel was created to take the best of both worlds (TN and IPS) and combine them.
Where VA panel excels is it's contrast ratio (min 3000:1), where you'd see the deepest and richest blacks.
it will have to be VA then, as colour contrast is very important for me. I wont be gaming also.

the 2 tricky colours are black and yellow, for printers light blue is also tricky eg a blue sky, a colour laser printer I had many years ago couldnt render blue skies properly.

for the moment I will continue using this one, but I will later upgrade the monitor.

I hadnt even heard of TN vs IPS vs VA, the problem is in this era we get inundated with a blizzard of info and eventually we become blasé

Also, it doesn't fall short on other aspects as well. VA panel color accuracy isn't as good as it is for IPS panel but it's close to the levels of IPS panel (considerably better than TN panel). It's viewing angle is also a notch smaller than that of an IPS panel but again, considerably better than that of a TN panel. Refresh rate wise, VA panel is more capable on different resolutions than IPS panel. Response time is another area where VA panel does good. While VA panel can't naturally be any faster than 4ms (just like IPS panel), it can achieve the magical 1ms response thanks to the software solution in it.
With VA panel monitors making waves lately, there aren't any major downsides of them. Availability used to be issue but not anymore.

Gaming wise, VA panel monitor is suited for all kinds of games. VA panel is like Jack of all trades but master of none (except when it comes to contrast ratio, there, VA panel is king).

your explanation has decided the matter for me! it will need to be VA, if it has 3000:1 contrast ratio, the 1000:1 of the other 2 systems is a deal breaker! if they were 2500:1 or something then maybe not.

its worth paying a premium to get noticeably better contrast.

but in a game, your mind is focussed on the action not the colours, so I agree its less important.




rest of this posting is off topic:


Yes, i know the electronic music pioneers and i sometimes listen to them. E.g "Jean Michelle Jarre - Oxygene part 4" i do like.

with all music, the quality of the music system really matters, eg the loudspeakers

if I connect my hifi system to my computer the same music is a totally different experience from when I use the cheaper but also ok speakers.

even rubbish music sounds interesting if the recording quality and playback equipment is top end!


Not quite. On the raves, there was different form of electronic music. Initially called EDM (Electronic Dance Music), but many genres did grow out of it. Nowadays, raves usually play "Hard Dance" and it's sub-genres, like Hard Acid Trance, Hard Trance and especially Hardstyle.
I have never participated in such things, so am less expert!

they were just things going on in the distance, I think I first heard of such maybe around 1985.

if you go to music gigs too much, you'll gradually go deaf.

my hearing is very good, because I quit listening to loud music around 1987.


sounds like someone hammering nails!

The trance i like to listen to, is Classic Trance and "Eurotrance" and it's sub-genres: Dream Trance, Anthem Trance and especially Epic (Euphoric) Trance. "Saltwater - The Legacy (Alphazone mix)" i linked before is Epic Trance.
Oh, from time-to-time, i also like to listen PSY Trance, namely Goa Trance and Psychedelic Trance.

Example of Psychedelic Trance;

View: https://www.youtube.com/watch?v=T2fj3FOsg0Q


The one in red cap is Raja Ram, one of the forerunners in Psychedelic Trance scene. Still active to this day, at age 83.
the trance music is "mood" music, to create an ambience or background, where there is a lot of repetition and gradual variation of theme.

what happens is each speed of change affects a different part of the brain, so if you have very gradual variation of theme eg with Jean Michel Jarre music and your trance music, that stimulates the part of your brain that handles gradual change. I would say each rate of change would be interesting, but is a different skill. eg with your trance music it can have a rapid beat, yet the overall variation is at a slow speed.


even the main disco music was kind of mood music, a background for people to disco dance.

I will listen to mood music, sometimes just for nostalgia, but I generally prefer "performance" music, by which I dont mean a rock concert, but where the music is the foreground, where you listen to the music directly and not do other stuff.

by performance I mean where there is a clearly defined progression from start to middle to finish.

the typical such music is maybe 3 minutes. which might not sound much, but even 10 seconds is a long time with music.

for this, I want a melody, a clearly defined tune that I can say whistle or sing. And maybe interesting lyrics.

the melody is maximal rate of change of variation. eg advert jingles are probably the max rate possible.


eg Abba songs are classic examples of this genre. and much of the pop music of the era that I followed, 1976-1985. 1985 CDs were now superceding vinyl, and the pop scene became less important culturally, as that revolved around the 45rpm singles. Also Scott Aitken and Waterman began manufacturing pop stars. where they composed the music, and just auditioned people who looked good on stage. up till 1985, most pop stars were self made. there were definitely composers creating works for others to perform, eg the Beegees I think even created a work for Kenny Rogers and Dolly Parton. But nonetheless Kenny and Dolly are self made stars. even today there are self made stars, but pop now is a fringe activity.

lyrics can be nonsense, or can be a ballad (a story), or can be a mood where the song expresses a sentiment, eg the earlier Donna Summer song. People today probably cannot comprehend how major the Donna Summer music was! in the 1977 era, her 2 songs were being played everywhere in the UK, and were quite radical. and in fact maybe 10 years ahead of their time.

the music is a victim of its own success, that it has inspired so much, that it now seems unremarkable. same way Spielberg films were very radical, but those films today look amateurish!

Donna Summer's other really famous song was "love to love you baby", it seems that was from 1975, we were overseas till 1976, so I heard that many months after it was produced, and it was being played all the time in the UK.

View: https://www.youtube.com/watch?v=oFrXXqq7QvQ


I couldnt find the original pop song only extended versions, some no good.

it has the repetition and very gradual change of variation of the trance music.

I actually find its better to just listen to music and not have a video as well, because with a video one gets drawn into the visuals and you cannot appreciate the musical side as much.

the look of a group is irrelevant, its the sound which matters. but with a video you start focussing on the look and dont notice the music so much. eg I find I dont appreciate lyrics with videos. but with the radio, the lyrics are the foreground perception.

most of the music I like I learnt from either the radio or vinyl, where no visuals. Now in the youtube era, I started watching videos, and when I see videos of the music I liked, it is unremarkable.

there was some music in 1976 which was just magic, then in recent years I have watched the pop videos and it has ruined the magic!

for me I would say 1977 was the pinnacle of popular culture, eg music, after that there is an ongoing decline.


if you listen without visuals, your imagination gets to work, and the visualisation of the sound is always much better than any video.

when I drive, I dont listen to music or the radio, total silence, where I focus on the road, and the sounds of the road, the sounds of the car engine, the sounds of other cars, reality.

for me the sounds of the road and the car are music!

I dont need to overlay a studio production on the experience!

when I listen to music, I entirely listen to music,
when I drive, I entirely drive.

if I have passengers, passengers always start talking, and I never look at them, only at the road. I may talk, but I focus on the road. I listen to the passengers, but I only look at the road and the dashboard.

by not combining activities, my memories are more sharply defined.

Status
Not open for further replies.
